HP

5YQ08AT

ⓘ

AUTHORIZED
PARTNER

$169.99 $219.85

HP Engage Imaging Barcode Scanner II Omni-directional 2D/1D USB Cable Scanner, RoHS Certified, IP52 Protected, 6ft Drop Resistant, PC Compatible Black - 5YQ08AT (1 Year Warranty)

Name: HP Engage Imaging Barcode Scanner II Omni-directional 2D/1D USB Cable Scanner, RoHS Certified, IP52 Protected, 6ft Drop Resistant, PC Compatible Black - 5YQ08AT (1 Year Warranty)
Brand: HP
SKU: 5YQ08AT
Price: 169.99 USD
Availability: InStock

Brand New

FREE Returns

Scanning Capability:

Both support (1D, 2D) See available options

Connectivity Technology:

Cable See available options
Wireless See available options

Product variants

2D/1D

Dual Scan

Omni-directional

360° Scan

6ft Drop

Resistant

IP52

Protected

100K Lux

Light Tolerance

5.68 oz

Lightweight

In stock, ready to ship

Share:

Share

Need help?

Ask Our Experts

Live Chat Send Message

Call Us

888.267.9566

Pairs well with

In stock! Ships within 1-2 business days.

30 days Free Return

Complimentary shipping & returns

1-Year Warranty

Downloads

Manufacturer Brochure PDF Document

Key Features

🔄 Omni-directional scanning with 360° roll angle for effortless barcode reading
📱 Advanced 2D/1D scanning capability for QR, Data Matrix, and traditional barcodes
💪 Durable design with 6.0 ft (1.8 m) drop resistance
🌟 100,000 lux maximum ambient light tolerance for reliable performance
💧 IP52 rated for dust and water resistance
🔌 USB connectivity with included 6.5 ft cable
🎯 65° reading angles for skew and pitch
📍 Supports multiple postal and stacked decode symbologies
🏢 Compatible with HP Retail Point of Sale Systems
♻️ RoHS certified for environmental compliance

HP Engage Imaging Barcode S...

$169.99 $219.85

Enhanced Scanning Flexibility with Hands-Free Stand

The HP Engage Imaging Barcode Scanner II comes with an ergonomically designed stand that transforms your scanning workflow. The adjustable stand features a sturdy base and flexible neck, allowing you to position the scanner at optimal angles for both handheld and hands-free scanning operations. With its integrated cable management system and USB connectivity, this setup ensures a clean, organized workspace while maintaining peak scanning efficiency.

Technical Specifications

Adjustable stand with 360-degree rotation capability
2.0m USB Type-A cable included
IP52-rated durable construction

Applications

High-volume retail checkout operations
Inventory management scanning
Document processing stations

Side view of HP Engage Imaging Barcode Scanner II mounted on stand with USB connection

Ergonomic Design Meets Maximum Efficiency

Experience superior scanning performance with the side profile view of the HP Engage Imaging Barcode Scanner II. The scanner's thoughtfully engineered form factor combines comfort with functionality, featuring a textured grip and balanced weight distribution. The integrated stand system enables smooth transitions between handheld and hands-free modes, perfect for varied scanning environments.

Technical Specifications

Ergonomic grip design with textured surface
Multi-angle adjustable mounting system
Plug-and-play USB connectivity

Applications

Retail point-of-sale operations
Warehouse scanning stations
Healthcare record management

Rear view of HP Engage Imaging Barcode Scanner II showing stand construction and cable management

Industrial-Grade Durability and Stability

The rear view of the HP Engage Imaging Barcode Scanner II showcases its robust construction and stability features. The weighted base provides unwavering support during intensive scanning sessions, while the reinforced cable routing prevents wear and strain. This design ensures reliable performance in demanding business environments.

Technical Specifications

Heavy-duty weighted base design
Integrated cable strain relief
Drop-resistant construction up to 1.8m

Applications

Manufacturing quality control
Distribution center processing
Retail inventory management

Close-up view of HP Engage Imaging Barcode Scanner II stand mechanism and mounting system

Precision-Engineered Stand Mechanism

The stand's innovative design features a precision-engineered mounting system that provides stable support while allowing quick adjustments. The curved support arm and specialized holder ensure smooth movement and secure positioning, enabling operators to maintain optimal scanning angles throughout their workday.

Technical Specifications

Multi-joint adjustment system
Secure mounting mechanism
Stable base with mounting points

Applications

Custom scanning station setup
Multiple user environments
High-traffic retail locations

Detailed view of HP Engage Imaging Barcode Scanner II scanning head and USB connection

Advanced Imaging Technology Integration

The HP Engage Imaging Barcode Scanner II's scanning head showcases its advanced imaging capabilities. The precision-engineered optics and imager window are designed for optimal code capture, while the streamlined form factor ensures comfortable operation during extended scanning sessions.

Technical Specifications

High-resolution imaging sensor
Omnidirectional scanning capability
Extended USB cable reach

Applications

Digital document processing
Package tracking systems
Access control verification

Dynamic angle view of HP Engage Imaging Barcode Scanner II showing complete system integration

Complete Scanning Solution Integration

The dynamic angle view of the HP Engage Imaging Barcode Scanner II demonstrates its complete integration capabilities. From the adjustable stand to the extended USB cable, every component is designed to work seamlessly together, providing a comprehensive scanning solution for diverse business environments.

Technical Specifications

Complete system integration
Flexible mounting options
Professional cable management

Applications

Multi-station deployment
Integrated POS systems
Mobile scanning stations

Product details

General Information

Manufacturer

HP Inc.

Manufacturer Part Number

5YQ08AT

Brand Name

HP

Product Name

Engage Imaging Barcode Scanner II

Product Type

Barcode Scanner

Technical Information

Connectivity Technology

Cable

Scanning Capability

2D
1D

Barcode Symbology Supported

1D:

Auto-discriminates all standard 1D codes (including GS1 DataBar linear codes)

2D:

Aztec Code
China Han Xin Code
Data Matrix
MaxiCode
QR Code
Micro QR Code

Postal decode symbologies:

Australian Post
British Post
China Post
IMB
Japanese Post
KIX Post
Planet Code
Postnet
Royal Mail Code (RM4SCC)

Stacked decode symbologies:

EAN/JAN Composites
GS1 DataBar Composites
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
Macro PDF
Micro PDF417
UPC A/E Composites

Image Sensor Type

Imager

Scan Pattern

Omni-directional

Cable Type Included

USB

Stand Included

Yes

Reading Angle (Skew)

65°

Reading Angle (Pitch)

65°

Reading Angle (Roll)

360°

Maximum Ambient Light

100000 lux

Drop Specification

Minimum Print Contrast

15%

Minimum Element Resolution (Code 39)

5 mil

Maximum Element Resolution (Code 39)

10 mil

Minimum Element Resolution (DataMatrix)

10 mil

Maximum Element Resolution (DataMatrix)

15 mil

Maximum Element Resolution (PDF417)

10 mil

Interfaces/Ports

Host Interface

USB

Physical Characteristics

Form Factor

Handheld

Product Color

Black

Height

4.3

Width

2.7

Length

6.5

Weight (Approximate)

5.68 oz

Miscellaneous

Package Contents

HP Engage Imaging Barcode Scanner II
Scanner stand
2.0 m (6.5 ft) USB Type-A Cable

Compatibility

<p>HP Retail Point of Sale Systems</p>

Ingress Protection (IP) Rating

IP52

Platform Supported

PC

Environmentally Friendly

Yes

Environmental Certification

RoHS

Included in the Box

Barcode Scanner
Scanner Stand
USB Cable
