BROADCOM - IMSOURCING BCM957416N4160C N210TP 2 x 10GBASE-T OCP 3.0 Adapter, 10Gigabit Ethernet Card

BROADCOM - IMSOURCING BCM957416N4160C N210TP 2 x 10GBASE-T OCP 3.0 Adapter, 10Gigabit Ethernet Card
BROADCOM - IMSOURCING BCM957416N4160C N210TP 2 x 10GBASE-T OCP 3.0 Adapter, 10Gigabit Ethernet Card

BROADCOM - IMSOURCING BCM957416N4160C N210TP 2 x 10GBASE-T OCP 3.0 Adapter, 10Gigabit Ethernet Card

Broadcom BCM957416N4160C

$318.49
FREE Returns
Brand New
Availability: In stock, ready to be shipped.
  • Free Shipping
  • Carbon Neutral
  • 1 Year Warranty
  • 30 Day Returns

Product Key Features

  • 2 x 10GBASE-T OCP 3.0 Adapter for high-speed network connectivity
  • PCI Express x8 host interface for easy installation
  • Environmentally friendly with RoHS certification
  • Supports 10GBase-T network technology for fast data transfer
  • Twisted pair media type supported
  • Plug-in card form factor for convenient use
  • OCP 3.0 bracket height for compatibility with various systems
  • Lightweight design weighing approximately 3.88 oz
$318.49
FREE Returns
FREE Delivery
Order in the next

hrs

mins

to be delivered on

Shipping information

-
+
Ask Our Experts
Call Us Now
888.267.9566
×

×
  • Description
  • Tech Specs
  • Refund Policy

Broadcom BCM957416N4160C

Based on Broadcom's scalable 10/25/50/100/200G Ethernet controller architecture, the N210TP 2x10GBASE-T OCP 3.0 adapter is designed to build highly-scalable, feature-rich networking solutions in servers for enterprise and cloud-scale networking and storage applications, including high-performance computing, telco, machine learning, storage disaggregation, and data analytics.

The N210TP 2x10GBASE-T OCP 3.0 adapter builds upon the success of the widely-deployed Broadcom architecture by combining a high-bandwidth Ethernet controller with a unique set of highly-optimized hardware acceleration engines to enhance network performance and improve server efficiency.

Driven by the growing need for higher server bandwidth and storage capacity to support new and emerging applications, enterprises, telcos and cloud providers are modernizing their data centers by adopting latest networking technologies, such as server virtualization and

NVMe-oF™. The resulting expansion in data volumes increases server-to-server traffic and CPU loads for networking tasks.

With its market-leading hardware acceleration technologies, the N210TP 2x10GBASE-T OCP 3.0 adapter addresses these performance and service demands of mega-scale data center networks with high throughput and advanced flow processing. Features such as TruFlow™ increase VM density up to 50 percent, freeing more CPU cycles for additional virtual machines. On-chip tunneling protocol processing for Geneve, VXLAN, and NVGRE provides up to a 5X throughput increase while lowering CPU utilization up to 90 percent compared to software-only solutions. These solutions also support advanced networking technologies such as RoCE, SDN and NFV, to facilitate the management of data networks and to enable service provider solutions.

Features

  • Standards-compliant 10GBASE-T dual-port OCP 3.0 adapter with line-rate, full-duplex throughput
  • NIC partitioning supporting 16 physical functions (PFs)
  • TruFlow™ engine for intelligent flow processing to increase server VM density and accelerate vSwitch processing
  • Industry's most secure PCIe NIC solution leveraging Broadcom's BroadSAFE® technology to provide unparalleled platform security via Silicon Root of Trust
  • New end-to-end congestion avoidance and management to anticipate and eliminate congestion before it happens
  • Support for advanced networking technologies including RoCE, SDN, NFV and virtualization
  • TruManage™ enhances server manageability and security for data center deployments


Applications

  • Cloud and Web2.0 data center servers
  • Enterprise data center servers
  • Private Cloud
  • Machine Learning (ML) clusters
  • High-Performance Computing (HPC) clusters
  • Multi-node container platforms
  • NVMe storage disaggregation (NVMe-oF)
  • Database servers

Return Policy

Time to Return

Standard Return Policy

Refund or Replacement within 30 days of the delivery date. All products that fall under the Standard Return Policy qualify for our 30-Day Hassle-Free Returns. Please see the section above for more details.

Replacement Only Return Policy

Replacement within 30 days of the delivery date.

Manufacturer Only Return Policy

Covered by the manufacturer's warranty. Please refer to the terms and conditions for the manufacturer's warranty or contact the manufacturer.

Holiday Extended Return Policies

Extended Holiday Return Policy.

Qualifying purchases of products displaying the " Extended Holiday Return Policy ", from November 1st, 2023 to December 25, 2023, are eligible for a Refund or Replacement until January 31, 2024.


Extended Holiday Replacement-Only Return Policy

Qualifying purchases of products displaying the " Extended Holiday Replacement-Only Return Policy ", from November 1st, 2023 to December 25, 2023, are eligible for a Replacement until January 31, 2024.

FAQ
The BROADCOM - IMSOURCING N210TP adapter uses a PCI Express x8 interface.
This adapter has two 10GBASE-T ports.
The BROADCOM - IMSOURCING N210TP adapter supports a maximum data transfer rate of 10 Gbit/s.
Yes, the BROADCOM - IMSOURCING N210TP adapter is environmentally friendly and RoHS certified.
This adapter is a plug-in card with an OCP 3.0 bracket height.
The BROADCOM - IMSOURCING N210TP adapter weighs approximately 3.88 oz.
This adapter supports twisted pair media type.
The BROADCOM - IMSOURCING N210TP adapter uses 10GBase-T network technology.
Yes, the BROADCOM - IMSOURCING N210TP adapter provides high-speed data transfer rates, improving network performance.
Yes, this adapter is designed to be compatible with OCP 3.0 form factor.
Yes, the BROADCOM - IMSOURCING N210TP adapter is RoHS certified, ensuring it meets environmental standards.
Absolutely! The BROADCOM - IMSOURCING N210TP adapter is suitable for server applications requiring high-speed network connectivity.
Yes, the BROADCOM - IMSOURCING N210TP adapter is ideal for data centers that require fast and reliable network connections.
Yes, the BROADCOM - IMSOURCING N210TP adapter is compatible with virtualization environments, providing high-performance network connectivity.
Yes, the BROADCOM - IMSOURCING N210TP adapter supports link aggregation, allowing you to combine multiple network connections for increased bandwidth and redundancy.
Yes, the BROADCOM - IMSOURCING N210TP adapter is designed for high-bandwidth applications, delivering fast and reliable network performance.
