Front view of white Wisenet ACE-8020R flateye security camera showing 5MP lens and IR LED array-alternate-image1

Three-quarter view of Wisenet ACE-8020R security camera highlighting weatherproof housing-alternate-image2

ACE-8020R

$119.99

Wisenet ACE-8020R 5MP Network Camera, Flateye, HD Recording, Night Vision 65ft, IR LED, IP67 IK10 Rated, Fixed Lens, White - ACE8020R (5 Year Warranty)

Name: Wisenet ACE-8020R 5MP Network Camera, Flateye, HD Recording, Night Vision 65ft, IR LED, IP67 IK10 Rated, Fixed Lens, White - ACE8020R (5 Year Warranty)
Brand: Wisenet
SKU: ACE-8020R
Price: 119.99 USD
Availability: InStock

Brand New

FREE Returns

Maximum Video Resolution:

1920x1080 See available options
3840x2160 See available options
2560x1920 See available options
2592x1944 See available options
2560x1440 See available options
2048x2048 See available options
3328x1872 See available options
2048x1536 See available options

Maximum Frame Rate:

60fps See available options
30fps See available options

Effective Camera Resolution:

2Megapixel See available options
8Megapixel See available options
5Megapixel See available options
4Megapixel See available options
6Megapixel See available options
3Megapixel See available options

Product variants

5MP

HD Resolution

65ft

Night Vision

IP67 IK10

Weatherproof

30fps

Frame Rate

f/1.6

Aperture

5.4W

Power

In stock, ready to ship

Share:

Share

Need help?

Order in the next

--

hrs

--

mins

to be delivered on Wednesday, Jul 16

Ask Our Experts

Live Chat Send Message

Call Us

888.267.9566

Pairs well with

In stock! Ships within 1-2 business days.

30 days Free Return

Complimentary shipping & returns

Limited warranty: 5 Year

Downloads

Manufacturer Brochure PDF Document

User Manual PDF Document

Key Features

🎥 5 Megapixel CMOS sensor with 2592 x 1944 resolution
🌙 65.62 ft IR night vision capability
🎯 Wide field of view: H:83.9°, V:63.4°, D:104°
🎬 30 fps maximum frame rate
🔍 f/1.6 aperture with 3.60mm fixed lens
🌐 Multiple video formats: TVI, CVI, CVBS, AHD
💪 IP67 weatherproof & IK10 impact protection
🌡️ Wide operating temperature: -22°F to 131°F
⚡ Low power consumption: 5.40W at 12V DC
✨ Advanced features: WDR, DNR, BLC, Day/Night

Wisenet ACE-8020R 5MP Netwo...

$119.99

Front view of white Wisenet ACE-8020R flateye security camera showing 5MP lens and IR LED array

5MP Crystal-Clear Surveillance with Advanced Night Vision

The Wisenet ACE-8020R combines powerful 5MP resolution with sophisticated imaging technology to deliver exceptional surveillance quality. Its fixed 3.6mm lens with f/1.6 aperture captures sharp, detailed footage across a wide 104-degree diagonal field of view. The camera's day/night functionality and built-in IR LEDs ensure reliable monitoring in complete darkness up to 65 feet.

Technical Specifications

5 Megapixel CMOS sensor for detailed surveillance
Fixed 3.6mm lens with f/1.6 aperture
104° diagonal field of view coverage

Applications

24/7 perimeter monitoring for commercial facilities
High-detail surveillance for retail environments
Critical infrastructure security monitoring

Three-quarter view of Wisenet ACE-8020R security camera highlighting weatherproof housing

Rugged Design Meets Environmental Protection

Built to withstand challenging conditions, the ACE-8020R features robust IP67 weatherproofing and IK10 impact resistance. The durable white housing protects internal components while maintaining optimal operating temperatures from -22°F to 131°F. This resilient construction ensures reliable performance in both indoor and outdoor installations.

Technical Specifications

IP67-rated weatherproof protection
IK10 impact resistance rating
Operating temperature range: -22°F to 131°F

Applications

Outdoor perimeter security deployment
Industrial facility monitoring
Harsh environment surveillance

Side angle view of Wisenet ACE-8020R camera emphasizing lens and image processing capabilities

Enhanced Image Processing for Complex Environments

Advanced image processing features including 3D Digital Noise Reduction and Wide Dynamic Range optimize video quality in challenging lighting conditions. The camera's sophisticated backlight compensation and automatic gain control ensure clear subject identification regardless of environmental variables. Multiple analog format support (TVI/CVI/AHD/CVBS) enables seamless integration with existing systems.

Technical Specifications

3D/2D Digital Noise Reduction
Wide Dynamic Range technology
Multiple analog format compatibility

Applications

High-contrast surveillance areas
Mixed lighting environment monitoring
Legacy system integration projects

Streamlined Installation with Flexible Mounting

The compact 4.7-inch diameter flateye design facilitates quick installation while maintaining a discreet profile. Backbox mounting compatibility and integrated cable management simplify deployment. Remote management capabilities allow for efficient system administration and maintenance, reducing operational overhead.

Technical Specifications

4.7-inch diameter compact design
Backbox mount compatibility
TCP-based remote management

Applications

Multi-camera system deployments
Discrete surveillance installations
Remote site monitoring applications

Product details

General Information

Manufacturer

Hanwha Group

Manufacturer Part Number

ACE8020R

Brand Name

Wisenet

Product Series

A

Product Model

ACE-8020R

Product Name

ACE-8020R 5MP Analog HD Flateye Camera

Product Type

Network Camera

Technical Information

HD Recording

Yes

Night Vision

Yes

Night Vision Distance

65.62 ft

Night Vision Type

Infrared

Display & Graphics

Image Sensor Type

CMOS

Image Sensor Size

1/2.5''

Color Supported

Color

Field of View

H:83.9°, V:63.4°, D:104°

Effective Camera Resolution

5 Megapixel

Video

Maximum Video Resolution

2592 x 1944

Maximum Frame Rate

30 fps

Analog Video Signal Format

TVI
CVI
CVBS
AHD

Lens

Lens Type

Fixed

Maximum Focal Length

3.60 mm

Lens Included

Yes

Maximum Aperture

f/1.6

Network & Communication

Connectivity Technology

Wired

Protocols

TCP

Remote Management

Yes

Power Description

Maximum Power Consumption

5.40 W

Input Voltage

12 V DC

Power Source Type

DC

Physical Characteristics

Mount Type

Backbox Mount

Form Factor

Flateye

Color Family

White

Product Color

White

Diameter

4.7''

Weight (Approximate)

14.46 oz

Environmental Conditions

Minimum Operating Temperature

-22°F (-30°C)

Maximum Operating Temperature

131°F (55°C)

Maximum Operating Humidity

90%

Miscellaneous

Features

Mirror
3D Digital Noise Reduction
2D Noise Reduction
Digital Noise Reduction
Gain Control
Back Light Compensation (BLC)
Wide Dynamic Range
White Balance
Ingress Protection
Built-in IR LED
Day/Night

Impact Protection Rating

IK10

Ingress Protection Rating

IP67

Country of Origin

Korea

Warranty

Limited Warranty

5 Year

Included in the Box

Network Camera
Mounting Hardware
Quick Guide

Accessories

Save 20%

Front view of white circular SBV-A14B back box showing multiple mounting holes and cable access points-alternate-image1

Hanwha Techwin

Hanwha Techwin SBV-A14B Back Box Mounting Box for Wisenet A-Series Cameras, Compat...

$39.99 $49.85

A-Series

Compatible

Gangbox

Adapter

Conduit

Access

Corner

Mount

Cable

Management

Similar Products

Save 24%

Wisenet

Wisenet Q Series 5MP Network IR Dome Camera, NDAA Compliant, HD Night Vision 65ft,...

$279.99 $370.49

5MP

Resolution

65ft

Night Vision

30fps

Frame Rate

H.265

Compression

WDR

Dynamic Range

RJ-45

Network

Save 8%

Wisenet

Wisenet Q Series 5MP Network IR Dome Camera, HD Night Vision 65ft, NDAA Compliant,...

$339.99 $370.49

5MP

CMOS Sensor

IR Vision

65ft Range

30fps

H.265 Video

WDR

Wide Dynamic

Multi Mount

7 Options

NDAA

Compliant

Save 4%

Wisenet

Wisenet Q Series 5MP Network IR Dome Camera, Wide Dynamic Range, Night Vision 65ft...

$449.99 $470.49

5MP

Resolution

65ft

Night Vision

H.265

Compression

IP66/IK10

Rated

PoE

Powered

SD

Storage

Save 26%

Wisenet

Wisenet Q 5MP Network IR Bullet Camera, Outdoor IP66 IK10, 2.8mm Lens, H.265/H.264...

$349.99 $470.89

5MP

Resolution

IR 65ft

Night Vision

IP66 IK10

Weatherproof

120dB WDR

Dynamic Range

H.265/H.264

Triple Codec

2.8mm f/2.0

Wide Lens

Honeywell Home

Honeywell Home 30 Series 5MP WDR Network Camera, Rugged Fisheye Design, HD IR Nigh...

$609.99

5MP

Resolution

Fisheye

Design

65ft

Night Vision

H.265

Compression

CMOS

Sensor

30fps

Frame Rate

FAQs

What are the key features of the Wisenet ACE-8020R camera?

The Wisenet ACE-8020R is a 5 Megapixel network camera featuring HD recording, infrared night vision up to 65.62 ft, and multiple video formats (TVI, CVI, CVBS, AHD). It offers advanced features including 3D Digital Noise Reduction, Wide Dynamic Range, Back Light Compensation, and Day/Night functionality. The camera is built with IP67 weather resistance and IK10 impact protection, making it suitable for both indoor and outdoor use. It captures video at up to 2592 x 1944 resolution at 30fps through its fixed 3.60mm lens with f/1.6 aperture.

What are the night vision capabilities of the ACE-8020R?

The ACE-8020R features built-in IR LED night vision with an impressive range of 65.62 feet (20 meters). The camera automatically switches between day and night modes for optimal performance in all lighting conditions. The infrared night vision, combined with the camera's 3D Digital Noise Reduction technology, ensures clear and detailed footage even in complete darkness, making it ideal for 24/7 surveillance applications.

What are the environmental specifications and durability features?

The Wisenet ACE-8020R is built for durability with IP67 ingress protection rating, making it dust-tight and waterproof when immersed up to 1 meter. It also features IK10 impact protection rating for enhanced physical security. The camera operates reliably in extreme temperatures from -22°F (-30°C) to 131°F (55°C) and can handle up to 90% humidity, making it suitable for challenging outdoor environments and various weather conditions.

What video formats and resolutions does the camera support?

The camera supports multiple analog video signal formats including TVI, CVI, CVBS, and AHD. It captures video at a maximum resolution of 2592 x 1944 (5 Megapixel) with frame rates up to 30 fps. The 1/2.5" CMOS image sensor provides excellent image quality, while the wide field of view (H:83.9°, V:63.4°, D:104°) ensures comprehensive coverage of the monitored area.

What are the power requirements and consumption specifications?

The Wisenet ACE-8020R operates on 12V DC power input and has a maximum power consumption of 5.40W. The camera uses a DC power source type, making it energy efficient while maintaining high performance. This low power consumption helps reduce operating costs while ensuring reliable 24/7 operation.
