Close-up view of green Cat6 ethernet cable RJ45 connectors showing gold-plated pins and transparent housing

Gold-Plated RJ45 Connectors for Reliable Data Transfer

The Cat6 network cable features precision-engineered RJ45 connectors with 50-micron gold plating, ensuring optimal signal integrity and corrosion resistance. Each connector incorporates StarTech.com's advanced design with transparent housing, allowing for visual confirmation of proper pin alignment and connection quality. The 24 AWG copper conductors and carefully constructed terminations minimize Near-End Crosstalk (NEXT) for consistent Gigabit performance.

Technical Specifications

  • 50-micron gold-plated contacts for superior conductivity
  • 24 AWG copper conductors for optimal signal transmission
  • Transparent connector housing for visual inspection

Applications

  • Data center network infrastructure deployment
  • Server room patch panel connections
  • Network switch to server connectivity
Side-by-side view of green Cat6 ethernet cable connectors showing internal wiring and CAT-6 marking

Clear Pin Alignment with Transparent Design

The transparent connector housing provides immediate visual confirmation of proper pin alignment and connection integrity. The CAT-6 marking clearly identifies the cable category, while the robust construction ensures reliable performance in demanding network environments. The combination of clear housing and quality components makes troubleshooting and maintenance more efficient.

Technical Specifications

  • Transparent housing for visual inspection
  • Clear CAT-6 identification marking
  • Eight-position modular design

Applications

  • Network certification and testing
  • Quality assurance verification
  • Professional network installations

Product details

General Information
Manufacturer

StarTech.com

Manufacturer Part Number

N6PATCH2GN

Brand Name

StarTech.com

Product Name

Cat. 6 Network Cable

Product Type

Network Cable

Technical Information
Cable Type

Category 6

Cable Characteristic

Patch Cable

Cable Length

2 ft

Connector Type on First End

RJ-45 Network - Male

Connector Gender on First End

Male

Connector on First End Details

1 x RJ-45 Network - Male

Connector Type on Second End

RJ-45 Network - Male

Connector Gender on Second End

Male

Connector on Second End Details

1 x RJ-45 Network - Male

Connector Plating

Gold

Features

Bend Resistant
Stranded
Strain Relief
Damage Resistant
Corrosion Resistant
Rust Resistant
Fray Resistant
Heat Resistant
Flexible
PoE

Shielding

No

Jacket Type

CMG

Device Supported

Network Device
Workstation
Hub

American Wire Gauge

24 AWG

Data Transfer Rate

10 Gbit/s

Boot Type

Snagless
Molded

Physical Characteristics
Product Color

Green

Jacket Material

Polyvinyl Chloride (PVC)

Weight (Approximate)

0.07 lb

Miscellaneous
Environmentally Friendly

Yes

Environmental Certification

WEEE
REACH
RoHS

Country of Origin

China

Warranty
Limited Warranty

Lifetime

Included in the Box

  • icon_list|cat6 cable|10ft Cat6 Cable icon

    Cat6 Cable

FAQs

What are the key features of the StarTech.com N6PATCH2GN Cat6 Network Cable?
The StarTech.com N6PATCH2GN features snagless RJ45 connectors with molded boots for strain relief, 24 AWG copper conductors, and 50-micron gold-plated connectors. It's a 2-foot green cable supporting up to 10 Gbit/s data transfer rates, making it ideal for Gigabit network connections. The cable is designed with multiple protective features including bend, damage, corrosion, rust, fray, and heat resistance. It's also PoE (Power over Ethernet) compatible and meets various environmental certifications including WEEE, REACH, and RoHS.
What is the maximum data transfer rate of this Cat6 cable?
This Cat6 network cable supports data transfer rates of up to 10 Gbit/s, making it suitable for high-performance Ethernet applications including Power-over-Ethernet and 4K or 1080p video streaming. The cable's 24 AWG copper conductors and quality construction ensure reliable high-speed connectivity while maintaining acceptable Near-End Crosstalk (NEXT) limits.
What devices can this network cable connect?
The StarTech.com Cat6 cable is compatible with multiple devices including network devices, workstations, and hubs. It's particularly well-suited for connecting a wall jack to a laptop docking station or desktop computer. The cable features RJ45 male connectors on both ends, making it versatile for various networking applications and standard Ethernet connections.
What protective features does this cable include?
This cable includes numerous protective features: snagless RJ45 clips to prevent snagging during installation, molded boots for connector strain relief, and resistance to bending, damage, corrosion, rust, fraying, and heat. The cable's construction also includes gold-plated connectors to prevent signal loss due to oxidation or corrosion, ensuring long-term reliability and performance.
What is the warranty period for this StarTech.com cable?
The StarTech.com N6PATCH2GN Cat6 Network Cable comes with a lifetime warranty from the manufacturer, ensuring guaranteed reliability and long-term peace of mind for your network infrastructure investment.
