PrismStation PS-5AC with integrated mounting system and adjustment mechanism

Industrial-Grade Mounting System

The PrismStation AC incorporates a robust mounting solution designed for long-term reliability. The precision-engineered mounting bracket ensures stable alignment even in challenging environmental conditions. This industrial-strength design maintains precise positioning for optimal signal strength while providing easy access for maintenance and adjustments.

Technical Specifications

  • Heavy-duty mounting bracket design
  • Precise alignment adjustment system
  • Weather-resistant construction

Applications

  • Tower installations
  • Rooftop deployments
  • Multi-point network configurations
Different horn antenna options for PrismStation PS-5AC showing coverage angles

Customizable Coverage Patterns

The PrismStation AC offers multiple horn antenna options to perfectly match your coverage requirements. From focused 30° beams to wide 90° sector coverage, each antenna option maintains superior interference rejection while delivering optimal gain. This flexibility allows network designers to create precisely tailored coverage patterns for any deployment scenario.

Technical Specifications

  • Interchangeable horn antennas (30°, 45°, 60°, 90°)
  • Consistent gain across coverage patterns
  • Optimized side-lobe suppression

Applications

  • Custom coverage area design
  • Sector optimization
  • Interference mitigation planning

Product details

General Information
Manufacturer

Ubiquiti Inc.

Manufacturer Part Number

PS-5AC-US

Brand Name

Ubiquiti

Product Line

PrismStation AC

Product Model

PS-5AC

Product Name

PrismStation PS-5AC Wireless Bridge

Product Type

Wireless Bridge

Technical Information
Wireless LAN Standard

IEEE 802.11ac

Frequency Band

5 GHz

Wireless Transmission Speed

450 Mbit/s

Interfaces/Ports
Ethernet Technology

Gigabit Ethernet

Number of Network (RJ-45) Ports

1

PoE PD Port

Yes

VGA

No

HDMI

No

USB

No

Powerline

No

Management Port

No

Physical Characteristics
Form Factor

Pole-mountable

Height

7.2

Width

6.9

Depth

6.9

Weight (Approximate)

2.36 lb

Miscellaneous
Package Contents

  • PrismStation PS-5AC Wireless Bridge
  • 24V, 1A Gigabit PoE Adapter
  • Pole-Mount Kit

Warranty
Limited Warranty

1 Year

Included in the Box

  • icon_list|prismstation ps-5ac|PrismStation PS-5AC Main unit icon

    PrismStation PS-5AC

  • icon_list|poe adapter|60W PoE adapter icon

    PoE Adapter

  • icon_list|pole-mount kit|Pole-Mount Kit Mounting hardware icon

    Pole-Mount Kit

FAQs

What is the maximum wireless transmission speed of the Ubiquiti PrismStation PS-5AC?
The Ubiquiti PrismStation PS-5AC delivers wireless transmission speeds of up to 450 Mbit/s on the 5 GHz frequency band. With Ubiquiti's advanced airMAX ac processor, the device can achieve actual throughput speeds of up to 500+ Mbps in real-world conditions, making it ideal for high-bandwidth applications and point-to-point wireless bridges.
What are the key features of the PrismStation PS-5AC's airPrism technology?
The PrismStation PS-5AC's airPrism technology features an active RF filter specifically designed to combat tower co-location interference. It functions without requiring communication between radios and works effectively even with noise from other vendors' equipment. The technology enables greater system capacity and improved throughput by reducing out-of-band energy, making it particularly effective in crowded RF environments.
What mounting options and physical specifications does the PS-5AC have?
The PS-5AC is pole-mountable and comes with a pole-mount kit included. It measures 7.2" in height, 6.9" in width, and 6.9" in depth, weighing approximately 2.36 lb. The device features a die-cast aluminum base for durability and includes an interchangeable antenna horn for flexible deployment options.
What connectivity options does the PrismStation PS-5AC offer?
The PrismStation PS-5AC features one Gigabit Ethernet (RJ-45) port with Power over Ethernet (PoE) PD support. It operates on the IEEE 802.11ac wireless standard in the 5 GHz frequency band. The device comes with a 24V, 1A Gigabit PoE adapter for power and data connectivity.
What antenna options are available for the PrismStation PS-5AC?
The PrismStation PS-5AC offers both asymmetrical and symmetrical horn antenna options. Asymmetrical options include 60° and 90° horns with naturally attenuated side lobes and low back radiation. Symmetrical options include 30° and 45° horns (default), which are ideal for cluster sector installations with high co-location requirements. All options provide industry-leading front-to-back ratio performance.
