Close-up view of two RJ45 connectors on blue Cat6 network cable showing gold-plated contacts and snagless boots

Gold-Plated RJ45 Connectors Enable Lightning-Fast Data Transfer

The N201-008-BL Cat6 cable features premium RJ45 connectors with gold-plated contacts, ensuring superior conductivity and minimal signal loss. The transparent connector design reveals the precision engineering of the 8-pin configuration, while the blue snagless boot provides both protection and easy cable identification. The molded strain relief and rugged construction work together to prevent cable damage during installation and regular use. This attention to durability, combined with Cat6's enhanced bandwidth capabilities, makes it ideal for high-speed network applications requiring reliable gigabit performance.

Technical Specifications

  • Gold-plated contacts for maximum conductivity
  • Snagless boot design prevents connector damage
  • 24 AWG stranded copper construction

Applications

  • High-density data center installations
  • Server room network connections
  • Network switch to patch panel connectivity

Product details

General Information
Manufacturer

Tripp Lite by Eaton

Manufacturer Part Number

N201008BL

Brand Name

Tripp Lite

Product Model

N201-008-BL

Product Name

N201-008-BL Cat.6 UTP Patch Network Cable

Product Type

Network Cable

Technical Information
Cable Type

Category 6

Cable Characteristic

Patch Cable

Cable Length

8 ft

Connector Type on First End

RJ-45 Network - Male

Connector on First End Details

1 x RJ-45 Network - Male

Connector Type on Second End

RJ-45 Network - Male

Connector on Second End Details

1 x RJ-45 Network - Male

Connector Plating

Gold

Contact Plating

Copper

Features

Stranded
Rugged
Strain Relief
Flexible
Molded
Crosstalk Protection
Corrosion Resistant

Device Supported

Switch
Network Adapter
Network Device
Router
Server
Modem
Hub

American Wire Gauge

24 AWG

Data Transfer Rate

1 Gbit/s

Boot Type

Snagless

Physical Characteristics
Product Color

Blue

Miscellaneous
Environmentally Friendly

Yes

Environmental Certification

RoHS

Country of Origin

China

Warranty
Limited Warranty

Lifetime

Included in the Box

  • icon_list|cat6 cable|10ft Cat6 Cable icon

    Cat6 Cable

FAQs

What are the key features of the Tripp Lite N201-008-BL network cable?
The Tripp Lite N201-008-BL is a Cat6 UTP patch cable featuring snagless RJ45 connectors, gold-plated contacts, and a rugged PVC jacket. It's an 8-foot blue cable that supports speeds up to 1 Gbps, with 24 AWG four-pair stranded construction. Key features include strain relief for flexibility, corrosion-resistant contacts, crosstalk protection, and molded connectors for durability. The cable is designed for high-density data centers and is compatible with various network devices including switches, routers, servers, and modems.
What is the maximum data transfer speed of this cable?
The Tripp Lite N201-008-BL supports data transfer speeds up to 1 Gigabit per second (1 Gbps) and frequencies up to 550 MHz. It's compatible with 1000Base-T Ethernet, 10/100Base-T Ethernet, 100 Mbps TPDDI, 155 Mbps ATM, ISDN, voice, and Token Ring Type 3 applications, making it suitable for high-speed network connections in modern networking environments.
What devices is this cable compatible with?
This cable is compatible with a wide range of network devices including switches, network adapters, routers, servers, modems, and hubs. It's specifically designed for high-density data centers and can be used for distributing data, voice, and video through various networking equipment. The cable meets IEEE 802.3ab, 802.5, and ISO/IEC 11801 standards, ensuring broad compatibility with modern networking infrastructure.
What type of connectors does the cable use and how are they protected?
The cable features RJ45 male connectors on both ends with a snagless boot design that protects the locking tabs from damage during installation and removal. The connectors use gold-plated copper contacts for maximum conductivity and minimal data loss. They also include integral strain relief for enhanced flexibility and stress reduction, helping prevent cable and connector damage during use.
What is the warranty coverage for this cable?
The Tripp Lite N201-008-BL comes with a lifetime limited warranty, demonstrating the manufacturer's confidence in the product's quality and durability. This warranty coverage provides long-term protection for your investment and ensures support if any issues arise with the cable's performance or construction.
