Close-up view of Monoprice Cat6 UTP network cable showing exposed twisted pairs in blue, orange, green, and brown with red outer jacket

Pure Copper Cat6 Cable: Enterprise-Ready Performance for Custom Network Solutions

This high-performance Cat6 cable features 23AWG solid pure copper conductors, delivering superior signal integrity and bandwidth capabilities up to 550MHz. The plenum-rated red jacket houses four precisely twisted pairs, each color-coded for proper termination and optimal cross-talk prevention. Engineered for maximum flexibility in network design, this bulk cable enables custom-length installations that eliminate cable clutter while maintaining full compliance with UL Code 444 and TIA-568-C.2 standards. The unshielded twisted pair (UTP) construction provides reliable performance for modern network applications while keeping costs efficient.

Technical Specifications

  • 23AWG solid pure copper conductors for optimal signal transmission
  • 550MHz bandwidth capacity for high-speed data transfer
  • CMP Plenum fire rating for installation safety compliance

Applications

  • Custom network infrastructure deployments
  • Data center and server room installations
  • Building-wide ethernet backbone implementation

Product details

General Information
Manufacturer

Monoprice, Inc

Manufacturer Part Number

13736

Brand Name

Monoprice

Product Name

Cat. 6 UTP Network Cable

Package Type

Bulk

Product Type

Network Cable

Technical Information
Cable Type

Category 6

Cable Length

1000 ft

Connector Type on First End

Bare Wire

Connector on First End Details

Bare Wire

Connector Type on Second End

Bare Wire

Connector on Second End Details

Bare Wire

Device Supported

Network Device

American Wire Gauge

23 AWG

Physical Characteristics
Product Color

Red

Warranty
Limited Warranty

Lifetime

Included in the Box

  • icon_list|cat6 cable roll|Cat6 Cable Roll Network cable icon

    Cat6 Cable Roll

FAQs

What are the key specifications of this Monoprice Cat6 cable?
This Monoprice Cat6 cable is a 1000ft bulk roll featuring 23AWG pure copper conductors with 550MHz bandwidth. It's an Unshielded Twisted Pair (UTP) cable with a CMP Plenum rating. The cable is designed for network devices and comes with bare wire ends for custom termination. It's rated Category 6 compliant and fully meets UL Code 444 and National Electrical Code TIA-568-C.2 standards.
What makes this cable different from cheaper alternatives?
The key differentiator is that this cable uses 100% pure bare copper conductors, not copper clad aluminum (CCA). This makes it fully compliant with UL Code 444 and National Electrical Code TIA-568-C.2 standards. The 23AWG thickness and 550MHz bandwidth ensure superior performance and reliability. Additionally, it comes with a lifetime warranty, demonstrating Monoprice's confidence in the product's quality.
Is this cable plenum rated?
Yes, this cable has a CMP (Plenum) fire safety rating, making it suitable for installation in plenum spaces such as drop ceilings or raised floors. This rating means the cable meets strict fire safety standards and produces minimal smoke and toxic fumes in case of fire, which is essential for installations in air handling spaces.
What is the maximum bandwidth of this Cat6 cable?
This Cat6 cable supports a bandwidth of 550MHz, which exceeds the standard Cat6 requirements. This high bandwidth capacity ensures reliable high-speed data transmission and provides excellent performance for modern networking applications, including Gigabit Ethernet.
How long is the warranty for this cable?
This Monoprice Cat6 cable comes with a lifetime warranty, providing long-term protection for your investment. This comprehensive warranty coverage demonstrates Monoprice's commitment to quality and customer satisfaction, ensuring peace of mind for professional installations.
