IOGEAR 4K KVMP switch with included cables and power adapter package contents display

Complete Connectivity Kit for Seamless Multi-Computer Control

The IOGEAR GCS1934H comes with everything needed for immediate setup and operation. The comprehensive package includes four HDMI cables, four USB 3.0 cables, and four audio cable sets, all measuring 6 feet in length. This complete solution ensures optimal connectivity between your computers and peripherals while maintaining the highest quality signal transmission for 4K displays.

Technical Specifications

  • Full accessory kit with 4 sets of 6ft cables
  • USB 3.0 SuperSpeed data transfer support
  • Integrated power adapter for reliable operation

Applications

  • IT department workstation setup
  • Multi-computer control room installation
  • Professional video editing station deployment
Front view of IOGEAR 4K KVMP switch showing control panel and USB port

Intuitive Front Panel Control for Quick Computer Switching

The sleek front panel features an elegant control interface with dedicated buttons for each connected computer. The clear layout includes status indicators and a USB 3.0 port for convenient peripheral access. The audio jack enables direct connection of speakers or headphones, while the intuitive button arrangement allows for effortless switching between connected systems.

Technical Specifications

  • Direct-access push buttons for 4 computers
  • Front-mounted USB 3.0 port
  • Integrated audio controls

Applications

  • Multi-system monitoring stations
  • Design studio workstation management
  • Healthcare imaging system control
Angled view of IOGEAR 4K KVMP switch showing compact design

Space-Efficient Design with Premium Build Quality

The compact form factor maximizes desk space while maintaining professional-grade durability. At just 10.3 inches wide and 1.7 inches tall, this KVMP switch fits perfectly in any workspace. The robust metal housing ensures long-term reliability, while the clean lines and minimalist aesthetic complement modern office environments.

Technical Specifications

  • Compact 10.3" x 2.9" x 1.7" dimensions
  • Durable metal construction
  • Professional matte black finish

Applications

  • Space-constrained workstations
  • Server room installations
  • Desktop command centers
Rear panel view of IOGEAR 4K KVMP switch showing all connection ports

Extensive Rear Port Configuration for Maximum Flexibility

The comprehensive rear panel provides all necessary connections for complete system integration. Each computer station features dedicated HDMI, USB 3.0, and audio ports, ensuring clean cable management. The console section includes USB peripheral connections, HDMI output, and RS-232 control port, supporting advanced automation and remote management capabilities.

Technical Specifications

  • 4 sets of HDMI and USB 3.0 ports
  • RS-232 serial control interface
  • Dedicated audio ports for each computer

Applications

  • Advanced multi-system integration
  • Automated control room setups
  • Professional broadcast environments

Product details

General Information
Manufacturer

IOGEAR, Inc

Manufacturer Part Number

GCS1934H

Brand Name

IOGEAR

Product Name

4-Port 4K KVMP Switch with HDMI Connection, USB 3.0 Hub, and Audio (TAA)

Packaged Quantity

1

Product Type

KVM Switchbox

Technical Information
Number of Computers Supported

4

Number of Local Users Supported

1

Video
Maximum Video Resolution

4096 x 2160

Interfaces/Ports
USB

Yes

HDMI

Yes

Number of USB Ports

7

Number of HDMI Ports

5

Physical Characteristics
Height

1.7

Width

10.3

Depth

2.9

Weight (Approximate)

1.90 lb

Miscellaneous
Package Contents

  • 4-Port 4K KVMP Switch with HDMI Connection, USB 3.0 Hub, and Audio (TAA)
  • 4 x HDMI Cables (6ft.)
  • 4 x USB 3.0 Cables (6ft.)
  • 4 x Audio Cable Set (6ft.)
  • 1 x Power Adapter
  • 1 x QSG

Environmentally Friendly

Yes

Environmental Certification

WEEE
RoHS

Country of Origin

Taiwan

TAA Compliant

Yes

Warranty
Limited Warranty

3 Year

FAQs

What is the maximum video resolution supported by the IOGEAR GCS1934H KVMP Switch?
The IOGEAR GCS1934H supports Cinema 4K resolution up to 4096 x 2160 at 60Hz refresh rate. This high-resolution capability makes it ideal for healthcare, engineering, design, and federal applications where crystal-clear image quality is essential.
How many computers can be connected to this KVMP switch?
The IOGEAR GCS1934H supports connections for up to 4 HDMI-enabled computers simultaneously. Each computer can be connected using the included HDMI and USB 3.0 cables, allowing you to switch between them while sharing a single monitor, keyboard, and mouse setup.
What are the different methods available for switching between computers?
The GCS1934H offers multiple switching methods: using the push-button on the front panel, keyboard hotkey combinations, clicking the wheel button on a 3-button USB mouse, or through RS-232 commands. This flexibility allows users to choose their preferred method for seamless switching between connected computers.
What comes included in the package?
The package includes the 4-Port 4K KVMP Switch unit, 4 HDMI cables (6ft each), 4 USB 3.0 cables (6ft each), 4 audio cable sets (6ft each), a power adapter, and a Quick Start Guide (QSG). All necessary cables are provided for complete setup right out of the box.
What are the USB capabilities of this KVMP switch?
The GCS1934H features USB 3.1 Gen1 ports that support SuperSpeed data transfer rates up to 5 Gbps. It includes 7 USB ports in total and maintains backward compatibility with USB 2.0 and USB 1.1 devices, allowing for connection of various peripherals and storage devices.
