SIIG DisplayPort to VGA adapter showing full adapter body with DisplayPort connector and VGA output port

Seamless Display Connectivity with High-Speed Performance

The SIIG DisplayPort to VGA adapter brings together modern DisplayPort technology with legacy VGA displays. This compact adapter delivers crystal-clear video output at resolutions up to 1920x1200, ensuring your content looks sharp and professional. With support for high-speed data transfer rates of up to 2.7Gbps, this adapter maintains signal integrity for smooth, uninterrupted viewing.

Technical Specifications

  • Supports data transfer rates up to 2.7Gbps for smooth video transmission
  • Built-in 8KV ESD protection for device safety
  • Compatible with resolutions up to 1920x1200 for HD display

Applications

  • Connecting modern laptops to legacy VGA projectors
  • Setting up conference room display systems
  • Extending monitor setups in office environments
Close-up view of SIIG adapter's VGA output port with blue connector and mounting screws

Robust VGA Output with Industrial-Grade Design

The adapter's VGA output port features a sturdy metal housing with secure mounting screws, ensuring a stable connection for your display setup. The blue-colored VGA port provides easy visual identification and proper alignment for quick connections. The durable construction and premium components guarantee reliable performance in demanding professional environments.

Technical Specifications

  • Metal-reinforced VGA port with mounting screws
  • 15-pin HD female connector for universal VGA compatibility
  • Automatic monitor detection for plug-and-play operation

Applications

  • Permanent installation in meeting rooms
  • Digital signage display connections
  • Educational facility display systems
Detailed view of SIIG adapter's DisplayPort connector with latching mechanism

Premium DisplayPort Interface for Reliable Connections

The DisplayPort connector features a latching mechanism for secure attachment to your source device. Built with premium copper conductors and precise engineering, this interface ensures consistent signal transmission and durability. The ergonomic release button allows for easy disconnection while preventing accidental cable removal during use.

Technical Specifications

  • 20-pin DisplayPort male connector with latch mechanism
  • Premium copper conductors for optimal signal quality
  • EDID and MCCS pass-through support

Applications

  • Workstation setup with multiple displays
  • Professional presentation systems
  • IT infrastructure deployments

Product details

General Information
Manufacturer

SIIG, Inc

Manufacturer Part Number

CB-DP0N11-S1

Brand Name

SIIG

Product Name

DisplayPort to VGA Adapter Converter

Packaged Quantity

1

Product Type

Video Cable

Technical Information
Cable Type

DisplayPort/VGA

Connector Type on First End

DisplayPort 1.1a Digital Audio/Video - Male

Connector on First End Details

1 x 20-pin DisplayPort 1.1a Digital Audio/Video - Male

Connector Type on Second End

HD-15 - Female

Connector on Second End Details

1 x 15-pin HD-15 - Female

Conductor

Copper

Device Supported

Monitor
Notebook
Video Device

Physical Characteristics
Product Color

Black

Weight (Approximate)

0.09 lb

Miscellaneous
Additional Information

  • Compliant with DisplayPort standards, supporting 1.62Gbps and 2.7Gbps
  • Supports 1080p and PC graphics resolution up to 1920x1200
  • Supports 8-bit per color RGB color format
  • Supports full DisplayPort link training
  • Supports EDID and MCCS pass-through
  • Automatic monitor plug and unplug detect for VGA output
  • Compact design with 8KV ESD protection

Certifications & Standards

  • CE
  • FCC

Environmentally Friendly

Yes

Environmental Certification

RoHS

Country of Origin

China

Included in the Box

  • icon_list|Main unit|Lift Ergo Mouse Main unit icon

    DisplayPort to VGA Adapter - Main unit

FAQs

What is the maximum resolution supported by this DisplayPort to VGA adapter?
This SIIG DisplayPort to VGA adapter supports resolutions up to 1920x1200 for PC graphics and 1080p for video content. It's compatible with DisplayPort standards and can handle data rates of 1.62Gbps and 2.7Gbps, ensuring high-quality video output for most modern display needs.
What devices can I connect using this adapter?
This adapter is designed to connect DisplayPort-equipped computers and notebooks to VGA displays and monitors. It features a DisplayPort 1.1a male connector on one end and a 15-pin HD-15 female (VGA) connector on the other end, making it ideal for connecting modern computers to legacy VGA monitors or projectors.
Does this adapter have any protection features?
Yes, the adapter features 8KV ESD (Electrostatic Discharge) protection, which helps prevent damage from static electricity. It also includes automatic monitor plug and unplug detection for VGA output, ensuring safe and reliable connections. The adapter is built with copper conductors for optimal signal transmission.
What video standards and features does this adapter support?
The adapter supports multiple video standards including 8-bit per color RGB color format, full DisplayPort link training, and EDID/MCCS pass-through. It's compliant with DisplayPort standards and supports data rates of 1.62Gbps and 2.7Gbps, ensuring compatibility with a wide range of display devices.
Is this adapter environmentally certified?
Yes, this SIIG adapter is environmentally friendly and RoHS certified, ensuring it meets strict environmental standards for electronic components. It also comes with CE and FCC certifications, guaranteeing compliance with international safety and electromagnetic compatibility standards.
