Cisco IE-2000-8TC-B Ethernet Switch (IE-2000-8TC-B) Main image

Cisco IE-2000-8TC-B Ethernet Switch

by Cisco
Availability:
in stock, ready to be shipped
$1,364.97 - $1,364.97
$1,364.97
$1,364.97 - $1,364.97
$1,364.97

New

FREE SHIPPING FOR DOMESTIC ORDERS

Delivery time

We ship orders 24-48 hours after they have been placed. We do not charge before we ship them out. It might take up to an additional 48 hours to ship international orders.

Carbon-neutral shipping with Shopify Planet
All deliveries are carbon neutral
Powered by Shopify Planet

Cisco IE-2000-8TC-B

The Cisco® Industrial Ethernet 2000 (IE 2000) Series is a range of compact, industrially ruggedized access switches. IE 2000 series provide customers with ease of use, secure access, and industry leading convergence using Cisco Resilient Ethernet Protocol (REP). Multiple industries such as automotive, oil and gas, mining, transportation, and energy companies are all increasingly requiring IP based networks in their production areas. The newest IE 2000 additions have been designed to support access layer connectivity and to meet the increasing needs for security, voice, and video traffic across industrial networks.

Cisco IE-2000-8TC-B Tech Specs

General Information
Manufacturer:Cisco Systems, Inc
Manufacturer Part Number:IE-2000-8TC-B
Brand Name:Cisco
Product Series:IE-2000
Product Model:IE-2000-8TC-B
Product Name:IE-2000-8TC-B Ethernet Switch
Product Type:Ethernet Switch
Interfaces/Ports
Total Number of Network Ports:10
Token Ring Port:No
LRE Port:No
Uplink Port:Yes
Bypass:No
Modular:No
Management Port:Yes
USB:No
Stack Port:No
Number of Network (RJ-45) Ports:8
Media & Performance
Media Type Supported:Twisted Pair
Twisted Pair Cable Standard:Category 5
Ethernet Technology:Fast Ethernet
Network Technology:10/100Base-TX
I/O Expansions
Number of Total Expansion Slots:2
Expansion Slot Type:SFP
Shared SFP Slot:Yes
Number of SFP Slots:2
Network & Communication
Layer Supported:2
Management & Protocols
Manageable:Yes
Management:
  • Telnet
  • Web Base Management
  • SNMP
  • CNA
  • VLAN
  • CiscoWorks LAN Management Solution (LMS)
  • DHCP
Memory
Standard Memory:256 MB
Maximum Memory Supported:1 GB
Memory Technology:DRAM
Flash Memory:64 MB
Memory Card Supported:SD
Power Description
PoE (RJ-45) Port:No
Input Voltage:60 V DC
Power Source:Power Supply
Redundant Power Supply Supported:Yes
Physical Characteristics
Form Factor:Rail-mountable
Desktop
Miscellaneous
Certifications & Standards:

Safety:

  • UL/CSA 60950-1
  • EN 60950-1
  • CB to IEC 60950-1 (with country deviations)
  • NOM to NOM-019-SCF1 (through partners and distributors)
  • CE Marking

Hazard:

  • ANSI/ISA 12.12.01 (Class 1, Div 2 A-D)
  • EN 60079-0, -15 ATEX certification (Class I, Zone 2 A-D)

EMC Emission and Community:

  • FCC 47 CFR Part 15 Class A
  • EN 55022A Class A
  • VCCI Class A
  • AS/NZS CISPR 22 Class A, AS/NZS CISPR 24
  • CISPR11 Class A, CISPR22 Class A
  • ICES 003 Class A
  • KCC -Korea
  • CE Marking
  • C-Tick (Australia)
  • Russia certification
  • Brazil certification
  • IEC/EN61000-4-2 (Electro Static Discharge), 15kV Air/8kV Contact
  • IEC/EN 61000-4-3 (Radiated Immunity, 10 and 20V/m)
  • IEC/EN 61000-4-4 (Fast Transients - 4kV power line, 4kV data line
  • IEC/EN 61000-4-5 (Surge 2 kV/1 kV)
  • IEC/EN 61000-4-6 (Conducted Immunity, 10V/emf)
  • IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)
  • IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)
  • IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)
  • IEC/EN 61000-4-11 (AC power Voltage Immunity)
  • IEC/EN 61000-4-29 (Voltage Dips Immunity)
  • IEC/EN 61000-6-1 (Immunity for Light Industrial Environments)
  • IEC/EN 61000-6-4 Class A
  • EN 61326

Shock and Vibration:

  • IEC 60068-2-27 (Operational Shock: 30G 11ms, half sine)
  • IEC 60068-2-27 (Non-Operational Shock 55-70G, trapezoidal)
  • IEC 60068-2-6, IEC 60068-2-64 (Operational Vibration 2g@10-500Hz)
  • IEC 60068-2-6, IEC 60068-2-64 (Non-operational Vibration)

Industry:

  • UL 508
  • CSA C22.2 No. 142
  • EN 61131-2 (Programmable Controllers)
  • Protective Coating
  • Substation (IEEE 1613, IEC 61850-3) KEMA
  • Lloyd's Register Type Approval - ENV2 or ENV3
  • British, German Lloyds
  • Marine (LR, BV, GL, DnV, Rina ABS, KR)
  • RA 156-165 Mhz 24 dBuV/M - Class A is 50 dBuV/M - Marine Band
  • Railway EN 50155
  • NEMA TS-2
  • IP30
  • ODVA Industrial EtherNet/IP
  • PROFINETv2

Corrosive Testing:

  • ISO-12944-6
  • IEC-60068-2-60

Humidity:

  • IEC 60068-52-2 (Salt Fog Mist, Test Kb) Marine environments
  • IEC 60068 -2-3
  • IEC 60068-2-30
Environmentally Friendly:Yes
Environmental Certification:RoHS
Warranty
Limited Warranty:1 Year
