IE-2000-4TS-G-L-Refurbished
Cisco IE-2000 Ethernet Switch, 4 RJ-45 Ports, 2 SFP Slots, Fast Ethernet 10/100Base-TX, Layer 2 Managed, Desktop/Rail-Mount, 256MB DRAM, SD Card Support - IE-2000-4TS-G-L (1 Year Warranty)
FREE Returns
Ethernet Ports
Fiber Slots
DRAM
Managed
Ruggedized
Desktop
Pairs well with
In stock! Ships within 1-2 business days.
30 days Free Return
Complimentary shipping & returns
Limited warranty: 1 Year
Key Features
- 🔌 6 Total Network Ports (4 RJ-45 + 2 SFP slots)
- 💾 256MB DRAM + 64MB Flash Memory with SD card support
- 🌐 Layer 2 Fast Ethernet with 10/100Base-TX technology
- 🔒 Advanced security with SNMPv3 and comprehensive management features
- 🏭 Industrial-grade with IP30 rating and extensive certifications
- ⚡ Redundant power supply support for reliability
- 🔄 MTBF of 374,052 hours for exceptional durability
- 🛠️ Desktop and Rail-mountable form factor
- 📊 Supports Web, CLI, Telnet, SNMP, VLAN, and QoS management
- 🌡️ Extensive shock, vibration, and environmental protection
Cisco IE-2000 Ethernet Swit...
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
We ship orders 24-48 hours after they have been placed. It might take up to an additional 48 hours to ship international orders.
-
Refund Policy
Standard Return Policy:
We offer a hassle-free 30-day returns policy for domestic (US)
orders, excluding non-refundable items. Refund or Replacement within 30
days of the delivery date. All products that fall under the Standard
Return Policy qualify for our 30-Day Hassle-Free Returns.Replacement Only Return Policy:
Replacement within 30 days of the delivery date.
Manufacturer Only Return Policy:
Covered by the manufacturer's warranty. Please refer to the terms and
conditions for the manufacturer's warranty or contact the manufacturer.
Product details
General Information
Manufacturer
Cisco Systems, Inc
Manufacturer Part Number
IE-2000-4TS-G-L
Brand Name
Cisco
Product Series
IE-2000
Product Model
IE-2000-4TS-G-L
Product Name
IE-2000-4TS-G-L Ethernet Switch
Product Type
Ethernet Switch
Interfaces/Ports
Total Number of Network Ports
6
Token Ring Port
No
LRE Port
No
Uplink Port
Yes
Bypass
No
Modular
No
Management Port
Yes
USB
Yes
Stack Port
No
Number of Network (RJ-45) Ports
4
Media & Performance
Media Type Supported
Twisted Pair
Twisted Pair Cable Standard
Category 5
Ethernet Technology
Fast Ethernet
Network Technology
10/100Base-TX
I/O Expansions
Number of Total Expansion Slots
2
Expansion Slot Type
SFP
Number of SFP Slots
2
Network & Communication
Layer Supported
2
Management & Protocols
Manageable
Yes
Management
- Web Based Management
- CLI
- Telnet
- SNMP
- CNA
- VLAN
- DHCP
- CiscoWorks LAN Management Solution
- QoS
- SNMPv3
Memory
Standard Memory
256 MB
Memory Technology
DRAM
Flash Memory
64 MB
Memory Card Supported
SD
Reliability
MTBF
374052 Hour
Power Description
PoE (RJ-45) Port
No
Power Source
Power Supply
Redundant Power Supply Supported
Yes
Physical Characteristics
Form Factor
Desktop
Rail-mountable
Height
5.1''
Width
3''
Depth
4.5''
Weight (Approximate)
2.45 lb
Miscellaneous
Certifications & Standards
Safety:
- UL/CSA 60950-1
- EN 60950-1
- CB to IEC 60950-1 (with country deviations)
- NOM to NOM-019-SCF1 (through partners and distributors)
- CE Marking
Hazard:
- ANSI/ISA 12.12.01 (Class 1, Div 2 A-D)
- EN 60079-0, -15 ATEX certification (Class I, Zone 2 A-D)
EMC Emission and Community:
- FCC 47 CFR Part 15 Class A
- EN 55022A Class A
- VCCI Class A
- AS/NZS CISPR 22 Class A, AS/NZS CISPR 24
- CISPR11 Class A, CISPR22 Class A
- ICES 003 Class A
- KCC -Korea
- CE Marking
- C-Tick (Australia)
- Russia certification
- Brazil certification
- IEC/EN61000-4-2 (Electro Static Discharge), 15kV Air/8kV Contact
- IEC/EN 61000-4-3 (Radiated Immunity, 10 and 20V/m)
- IEC/EN 61000-4-4 (Fast Transients - 4kV power line, 4kV data line
- IEC/EN 61000-4-5 (Surge 2 kV/1 kV)
- IEC/EN 61000-4-6 (Conducted Immunity, 10V/emf)
- IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)
- IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)
- IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)
- IEC/EN 61000-4-11 (AC power Voltage Immunity)
- IEC/EN 61000-4-29 (Voltage Dips Immunity)
- IEC/EN 61000-6-1 (Immunity for Light Industrial Environments)
- IEC/EN 61000-6-4 Class A
- EN 61326
Shock and Vibration:
- IEC 60068-2-27 (Operational Shock: 30G 11ms, half sine)
- IEC 60068-2-27 (Non-Operational Shock 55-70G, trapezoidal)
- IEC 60068-2-6, IEC 60068-2-64 (Operational Vibration 2g@10-500Hz)
- IEC 60068-2-6, IEC 60068-2-64 (Non-operational Vibration)
Industry:
- UL 508
- CSA C22.2 No. 142
- EN 61131-2 (Programmable Controllers)
- Protective Coating
- Substation (IEEE 1613, IEC 61850-3) KEMA
- Lloyd's Register Type Approval - ENV2 or ENV3
- British, German Lloyds
- Marine (LR, BV, GL, DnV, Rina ABS, KR)
- RA 156-165 Mhz 24 dBuV/M - Class A is 50 dBuV/M - Marine Band
- Railway EN 50155
- NEMA TS-2
- IP30
- ODVA Industrial EtherNet/IP
- PROFINETv2
Corrosive Testing:
- ISO-12944-6
- IEC-60068-2-60
Humidity:
- IEC 60068-52-2 (Salt Fog Mist, Test Kb) Marine environments
- IEC 60068 -2-3
- IEC 60068-2-30
Environmentally Friendly
Yes
Environmental Certification
RoHS
Warranty
Limited Warranty
1 Year
Included in the Box
Ethernet Switch
Power Adapter
Mounting Kit
Quick Guide
