Product details

General Information
Manufacturer

Belkin International, Inc

Manufacturer Part Number

F1DN202KVMUN4

Brand Name

Belkin

Product Line

Secure

Product Model

F1DN202KVM-UN-4

Product Name

Universal 2nd Gen Secure KVM Switch, 2-Port Dual Head w/CAC

Product Type

KVM Switchbox

Technical Information
Number of Computers Supported

2

Number of Local Users Supported

1

Video
Maximum Video Resolution

3840 x 2160

Interfaces/Ports
USB

Yes

HDMI

Yes

DisplayPort

Yes

Number of USB Ports

7

Power Description
Input Voltage

120 V AC
230 V AC

Input Voltage Range

120V AC to 230V AC

Physical Characteristics
Form Factor

Desktop
Under Table

Miscellaneous
Country of Origin

United States

TAA Compliant

Yes

Warranty
Limited Warranty

1 Year

Included in the Box

  • icon_list|kvm switch|2-Port KVM Switch icon

    KVM Switch

  • icon_list|power adapter|LP4 Power adapter icon

    Power Adapter

  • icon_list|Mounting hardware|Rack Rails Mounting hardware icon

    Mounting Hardware

  • icon_list|user manual|User Manual Documentation icon

    User Manual

FAQs

What are the key security features of the Belkin F1DN202KVM-UN-4 Secure KVM Switch?
The Belkin F1DN202KVM-UN-4 features advanced security measures including optical data diodes and embedded peripheral emulation for each channel to prevent data leakage between computers. It meets NIAP Protection Profile 4.0 certification requirements and includes always-on active anti-tamper protection. The switch also features an 8th order elliptical audio filter to protect against ultrasonic attacks, making it ideal for government, military, and healthcare applications requiring strict security protocols.
What video resolutions and connections does this KVM switch support?
The Belkin F1DN202KVM-UN-4 supports up to 3840 x 2160 (4K) resolution with a 60Hz refresh rate. It features universal video compatibility through combo DisplayPort/HDMI connectors on each input and output. The switch is compatible with DisplayPort, HDMI, and DVI video outputs, eliminating the need for external converters. This versatility allows connection to both modern and legacy monitors while maintaining optimal display quality.
How many computers and displays can this KVM switch support?
This KVM switch supports 2 computers (2-port) and features dual-head display capability, allowing users to connect two monitors per computer. It supports one local user and includes 7 USB ports for peripheral connectivity. The dual-head feature enables users to work with multiple displays while maintaining secure isolation between different security enclaves.
What are the mounting options and installation capabilities?
The Belkin F1DN202KVM-UN-4 offers flexible mounting options with both desktop and under-table form factors. It's compatible with the Belkin KVM Remote Control with Integrated Keyboard, which helps declutter the desk space while maintaining efficient operation. These mounting options combined with the remote control capability enhance user experience by optimizing workspace organization.
What is the power specification for this KVM switch?
The Belkin F1DN202KVM-UN-4 operates with an input voltage range of 120V AC to 230V AC, making it versatile for different power environments. This wide voltage range ensures compatibility with both North American (120V) and European (230V) power standards, providing flexibility for international deployment.
