02374-001
$419.99
AXIS M30 4MP Indoor Network Dome Camera M3086-V, Wide Dynamic Range, Deep Learning Analytics, PoE, H.264/H.265, 130° View, Vandal-Resistant, TAA Compliant - 02374-001 (1 Year Warranty)
Brand New
FREE Returns
4MP
Resolution
130°
View Angle
PoE
Power
H.265
Codec
30fps
Frame Rate
IK08
Impact Rating
In stock, ready to ship
Order in the next
to be delivered on
Tuesday, Jul 15
--
hrs--
mins
Ask Our Experts
Call Us
888.267.9566
Pairs well with
In stock! Ships within 1-2 business days.
30 days Free Return
Complimentary shipping & returns
1-Year Warranty
Key Features
- 🎥 4MP resolution with 2688 x 1512 max resolution at 30fps
- 🌟 Wide Dynamic Range (WDR) & Lightfinder for superior low-light performance
- 📐 130° horizontal & 93° vertical field of view
- 🧠 Deep learning processing unit for advanced analytics
- 🔒 Built-in cybersecurity features with Axis Edge Vault
- 🎯 Supports H.264/H.265 with Zipstream technology
- 💪 IK08 vandal-resistant & IP42 dust/water protection
- ⚡ PoE (Power over Ethernet) enabled
- 💾 Edge storage with memory card support
- 🤖 Pre-installed AXIS Object Analytics with human/vehicle detection
AXIS M30 4MP Indoor Network...
$419.99
4MP Precision Lens with Advanced Light Management
The AXIS M3086-V features a sophisticated fixed 2.4mm lens with f/2.1 aperture, optimized for capturing crisp 4MP resolution footage in varying light conditions. The dome's clear protective housing ensures unobstructed views while safeguarding the precision optics within. Built-in WDR technology and Lightfinder capabilities work together to deliver exceptional image clarity across challenging lighting scenarios.
Technical Specifications
- 4 Megapixel resolution for detailed surveillance coverage
- Fixed 2.4mm lens with f/2.1 aperture for optimal light gathering
- 130° horizontal field of view for wide area monitoring
Applications
- Reception area monitoring requiring wide viewing angles
- Retail environments with mixed lighting conditions
- Office hallway surveillance with day/night transitions
Compact Design with Industrial-Grade Protection
The sleek mini dome form factor combines aesthetic appeal with robust security features. The vandal-resistant IK08-rated housing protects against impacts while maintaining a discreet profile. The IP42-rated construction prevents dust ingress and water drips, ensuring reliable operation in indoor environments. The bayonet mount system enables quick installation and maintenance access.
Technical Specifications
- IK08 impact resistance rating for vandal protection
- IP42 environmental protection against dust and water
- Bayonet mount system for tool-free maintenance
Applications
- High-traffic areas requiring tamper resistance
- Clean room environments needing dust protection
- Quick-service installations with minimal downtime
Edge Intelligence with Deep Learning Capabilities
Advanced onboard processing enables sophisticated analytics powered by deep learning technology. The integrated DLPU (Deep Learning Processing Unit) supports intelligent detection features including human and vehicle tracking. Combined with edge storage capabilities, this creates a powerful surveillance solution that can operate independently while seamlessly integrating with larger security systems.
Technical Specifications
- Built-in deep learning processing unit
- Edge storage support for local recording
- ACAP-ready for custom analytics applications
Applications
- Retail analytics requiring people counting
- Parking facilities needing vehicle detection
- Access points requiring motion tracking
Low-Profile Ceiling Mount with Enterprise Integration
The dome's architectural design enables seamless ceiling integration while maintaining full functionality. PoE capability simplifies deployment with single-cable installation for both power and data. The enterprise-grade cybersecurity features, including Axis Edge Vault, ensure secure operation within corporate networks. Multiple mounting options provide installation flexibility for various indoor environments.
Technical Specifications
- PoE-powered for simplified installation
- Built-in Axis Edge Vault security
- Multiple mounting configuration options
Applications
- Corporate office ceiling installations
- Educational facility monitoring
- Healthcare facility surveillance
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
We ship orders 24-48 hours after they have been placed. It might take up to an additional 48 hours to ship international orders.
-
Refund Policy
Standard Return Policy:
We offer a hassle-free 30-day returns policy for domestic (US)
orders, excluding non-refundable items. Refund or Replacement within 30
days of the delivery date. All products that fall under the Standard
Return Policy qualify for our 30-Day Hassle-Free Returns.Replacement Only Return Policy:
Replacement within 30 days of the delivery date.
Manufacturer Only Return Policy:
Covered by the manufacturer's warranty. Please refer to the terms and
conditions for the manufacturer's warranty or contact the manufacturer.
Product details
General Information
Manufacturer
Axis Communications
Manufacturer Part Number
02374001
Brand Name
AXIS
Product Series
M30
Product Model
M3086-V
Product Name
M3086-V Dome Camera
Product Type
Network Camera
Technical Information
HD Recording
Yes
Display & Graphics
Image Sensor Type
RGB CMOS
Color Supported
Color
Field of View
Horizontal field of view: 130° Vertical field of view: 93°
Effective Camera Resolution
4 Megapixel
Video
Video Formats
H.264 (MPEG-4 Part 10/AVC)
H.265 (MPEG-H Part 2/HEVC)
H.264M
H.264H
Zipstream
H.265
H.264
Maximum Video Resolution
2688 x 1512
Maximum Frame Rate
30 fps
Lens
Lens Type
Fixed
Maximum Focal Length
2.40 mm
Lens Included
Yes
Maximum Aperture
f/2.1
Exposure
Shortest Shutter Speed
1/38500 Second
Longest Shutter Speed
1/5 Second
Network & Communication
Connectivity Technology
Wired
Remote Management
Yes
Storage
Storage Type
Memory Card
Interfaces/Ports
HDMI
Yes
Network (RJ-45)
Yes
Power Description
Power Source Type
PoE
Physical Characteristics
Mount Type
Wall Mount
Ceiling Mount
Form Factor
Mini Dome
Durability
Impact Resistant
Dust Resistant
Vandal Resistant
Water Resistant
Product Color
White
Height
2.2
Diameter
4
Weight (Approximate)
5.29 oz
Environmental Conditions
Minimum Operating Temperature
32°F (0°C)
Maximum Operating Temperature
113°F (45°C)
Operating Humidity
85%
Miscellaneous
Features
Password Protection
Cross Line Detection
Removable IR Cut-off Filter
Built-in Microphone
Day/Night
Wide Dynamic Range
Multi-view Stream
HTTPS Encryption
Human Detection
Vehicle Detection
Indoor/Outdoor
Indoor
Impact Protection Rating
IK08
Ingress Protection Rating
IP42
TAA Compliant
Yes
Included in the Box
Dome Camera
Installation Guide
Similar Products
Vendor:AXIS
360° View
Four Sensors
5MP
HD Recording
H.264/H.265
Compression
IP66/IK10
Weather Rated
PTZ Control
Auto Tracking
PoE Ready
Power Options
Vendor:AXIS
360° View
Complete Coverage
4x 5MP
Quad Sensors
20 FPS
HD Recording
IP66/IK10
Rugged Build
Audio Detection
Sound Tracking
H.265/H.264
Video Codecs
Vendor:AXIS
4MP
Resolution
130°
Wide Angle
Deep Learning
Analytics
WDR
Imaging
PoE
Powered
IK08
Vandal Resistant
FAQs
What are the key features of the AXIS M3086-V Dome Camera?
The AXIS M3086-V is a 4MP indoor mini dome camera featuring Wide Dynamic Range (WDR) and Lightfinder technology for excellent image quality in challenging light conditions. It offers a wide 130° horizontal viewing angle, deep learning capabilities for advanced analytics, and supports H.264/H.265 with Zipstream for efficient bandwidth usage. The camera includes built-in cybersecurity features, edge storage capability, and is vandal-resistant with IK08 and IP42 ratings. It's powered via PoE and supports various mounting options for flexible installation.
What is the image quality and resolution of the AXIS M3086-V?
The AXIS M3086-V delivers 4 megapixel resolution with a maximum video resolution of 2688 x 1512 pixels at 30 fps. It uses an RGB CMOS sensor and features Lightfinder technology for clear color images in low light conditions. The camera includes Wide Dynamic Range (WDR) for balanced exposure in scenes with both bright and dark areas. The fixed 2.40mm lens with f/2.1 aperture provides a wide 130° horizontal and 93° vertical field of view.
What mounting options and physical specifications does the camera have?
The AXIS M3086-V features a compact mini dome design that can be mounted on walls or ceilings. The camera measures 4 inches in diameter and 2.2 inches in height, weighing approximately 5.29 ounces. It comes in white color and features a bayonet-fitted casing for easy installation and maintenance. The camera is vandal-resistant (IK08 rated) and offers IP42 protection against dust and dripping water.
What video compression formats does the camera support?
The camera supports multiple video compression formats including H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), H.264M, and H.264H. It also features Axis Zipstream technology, which works with both H.264 and H.265 to reduce bandwidth and storage requirements while maintaining image quality. This variety of compression options allows for flexible integration with different video management systems.
What are the camera's environmental specifications and operating conditions?
The AXIS M3086-V is designed for indoor use with an operating temperature range of 32°F (0°C) to 113°F (45°C). It can function in environments with up to 85% operating humidity. The camera features IP42 ingress protection rating for protection against dust and dripping water, making it suitable for various indoor installations. It's also impact-resistant with an IK08 rating for added durability.
