Product Key Features

  • Compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) security requirements
  • Restricted USB Connectivity - non-authorized HIDs (Human Interface Devices) or non-predefined CAC devices will be rejected / ignored
  • Always-on Chassis Intrusion Detection - renders the ATEN PSS PP v3.0 Secure KVM Switches inoperable when physical tampering is detected
  • Tamper-Evident Seals- provides visual indication of any attempt to access the ATEN PSS PP v3.0 Secure KVM Switches' internal components
  • Non-Reprogrammable Firmware - prevents reprogramming the ATEN PSS PP v3.0 Secure KVM Switches
$5,527.85
FREE Returns
-
+
Notify Me When Available
Ask Our Experts
Call Us Now
888.267.9566
×

×
  • Description
  • Tech Specs
  • Refund Policy

ATEN CS1184H

ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) standard certified by the National Information Assurance Partnership (NIAP).

ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSS PP v3.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtering and management, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.

With multi-layered security, ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) ensures high-level desktop security and data safekeeping for applications such as government agencies, finance, and other organizations that often handle sensitive or confidential data on separate networks.

More from the Manufacturer

4-Port USB HDMI Secure KVM Switch (PSS PP v3.0 Compliant)

  • Compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) security requirements
  • Always-on Chassis Intrusion Detection – renders the ATEN PSS PP v3.0 Secure KVM Switches inoperable when physical tampering is detected
  • Configurable Device Filtering – USB CAC Port can be configured to allow/reject whitelisted / blacklisted devices via Admin logon function or Windows-based application
  • Superior video quality – up to 4K (3840 x 2160 @ 30 Hz)**
4-Port USB HDMI Secure KVM Switch (PSS PP v3.0 Compliant)

Overview

ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) is compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) standard certified by the National Information Assurance Partnership (NIAP).
ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSS PP v3.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtering and management, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.
With multi-layered security, ATEN PSS PP v3.0 Secure KVM Switch (CS1184H) ensures high-level desktop security and data safekeeping for applications such as government agencies, finance, and other organizations that often handle sensitive or confidential data on separate networks.
Overview

Features

  • NIAP Common Criteria Compliant
  • Compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) security requirements


  • Multi-Layered Security
  • Restricted USB Connectivity - non-authorized HIDs (Human Interface Devices) or non-predefined CAC devices will be rejected / ignored
  • Always-on Chassis Intrusion Detection - renders the ATEN PSS PP v3.0 Secure KVM Switches inoperable when physical tampering is detected
  • Tamper-Evident Seals- provides visual indication of any attempt to access the ATEN PSS PP v3.0 Secure KVM Switches' internal components
  • Non-Reprogrammable Firmware - prevents reprogramming the ATEN PSS PP v3.0 Secure KVM Switches
  • Port selection via pushbuttons only to enhance security
  • LED indicators for peripheral filtering and KVM security status
  • Rugged metal enclosure


  • Data Channel Isolation and Unidirectional Data Flow
  • Data Channel Isolation - prevents data leakage between connected computers via isolated channel per port
  • Unidirectional Data Flow - ensures unidirectional data flow between the console devices and the selected computer
  • ATEN PSS PP v3.0 Secure KVM Switches control and isolate data flow between the console devices and connected computers
  • Supports analog audio (speaker only)*


  • User Data Protection
  • User Data Protection - Keyboard/Mouse data buffer is automatically purged when switching KVM port focus


  • Security Management
  • KVM Log Data - provides administrative functions for authorized administrator to audit KVM log data
  • Configurable Device Filtering - USB CAC Port can be configured to allow/reject whitelisted / blacklisted devices via Admin logon function or Windows-based application
  • Supports enable / disable CAC function by port


  • Superior Video Quality
  • Superior video quality - up to 4K (3840 x 2160 @ 30 Hz)**
  • Video DynaSync™ - Exclusive ATEN technology eliminates boot-up display problems and optimizes resolutions when switching between ports


* Only analog speaker data input is supported. The ATEN PSS PP v3.0 Secure KVM Switches does not convert digital audio to analog audio.
** HDMI Secure KVM Switch series supports console video output resolutions up to 4K @ 30 Hz.

Return Policy

Time to Return

Standard Return Policy

Refund or Replacement within 30 days of the delivery date. All products that fall under the Standard Return Policy qualify for our 30-Day Hassle-Free Returns. Please see the section above for more details.

Replacement Only Return Policy

Replacement within 30 days of the delivery date.

Manufacturer Only Return Policy

Covered by the manufacturer's warranty. Please refer to the terms and conditions for the manufacturer's warranty or contact the manufacturer.

Holiday Extended Return Policies

Extended Holiday Return Policy.

Qualifying purchases of products displaying the " Extended Holiday Return Policy ", from November 1st, 2023 to December 25, 2023, are eligible for a Refund or Replacement until January 31, 2024.


Extended Holiday Replacement-Only Return Policy

Qualifying purchases of products displaying the " Extended Holiday Replacement-Only Return Policy ", from November 1st, 2023 to December 25, 2023, are eligible for a Replacement until January 31, 2024.

FAQ
You can control up to 4 computers using this KVM switch. It allows you to easily switch between different computers using a single display and keyboard.
Yes, the ATEN 4 Port Single Display HDMI Secure KVM Switch supports HDMI connectivity, allowing you to connect your HDMI display to the switch for seamless control of multiple computers.
Absolutely! The ATEN KVM switch ensures secure data transmission between your computers and the connected display. You can trust that your sensitive information remains protected.
Yes, the ATEN 4 Port Single Display HDMI Secure KVM Switch is designed for user-friendly operation. Simply connect your computers and display, and you're ready to go. It's a hassle-free solution for efficient workspace management.
Yes, the KVM switch features multiple USB ports, allowing you to connect additional peripherals such as keyboards, mice, and USB storage devices. It offers versatile connectivity options for your convenience.
Yes, the ATEN 4 Port Single Display HDMI Secure KVM Switch is environmentally friendly. It is WEEE certified and RoHS compliant, meeting international standards for electronic waste management and restriction of hazardous substances.
The ATEN 4 Port Single Display HDMI Secure KVM Switch is manufactured in Taiwan, known for its high-quality technology products.
Yes, the ATEN KVM switch supports PS/2 connectivity, allowing you to connect PS/2 keyboards and mice to control your computers. It offers flexibility for different input devices.
The ATEN 4 Port Single Display HDMI Secure KVM Switch supports a maximum video resolution of 3840 x 2160, ensuring crisp and clear visuals on your display.
Yes, the ATEN KVM switch comes with a power cord and user instructions, providing you with everything you need to set up and use the switch. It's a complete package for your convenience.
Yes, the ATEN 4 Port Single Display HDMI Secure KVM Switch is compatible with both 230V AC and 120V AC power sources. It offers flexibility for different power configurations.
