Front view of Aiphone JP-DV video door station featuring a CMOS camera, speaker grille, nameplate, and call button in silver die-cast aluminum housing

Ultra-Wide 170° Field of View for Complete Entrance Coverage

The Aiphone JP-DV video door station features a premium CMOS camera with an expansive 170° horizontal and 100° vertical viewing angle, ensuring no visitor goes unnoticed. The die-cast aluminum construction offers exceptional durability while maintaining a sleek, professional aesthetic that complements any entrance. This surface-mount unit combines high-performance video capabilities with crystal-clear full-duplex audio communication. The weather-resistant design and low-light sensitivity of 5 lux ensure reliable operation in various environmental conditions, making it ideal for both residential and commercial applications.

Technical Specifications

  • Die-cast aluminum construction for enhanced durability and weather resistance
  • CMOS camera with 170° horizontal and 100° vertical viewing angles
  • 2-wire installation system with range up to 330 feet

Applications

  • Main entrance security monitoring for office buildings
  • Residential gate communication and visitor screening
  • Reception area visitor management in commercial facilities

Product details

General Information
Manufacturer

Aiphone Co., Ltd

Manufacturer Part Number

JP-DV

Brand Name

Aiphone

Product Series

JP

Product Model

JP-DV

Product Name

JP-DV Video Door Phone

Product Type

Video Door Phone

Technical Information
Communication Mode

Full-duplex

Wiring Type

2-wire

Maximum Wiring Distance

330 ft

Camera
Image Sensor Type

CMOS

Minimum Illumination

5 lux

Horizontal Viewing Angle

170°

Vertical Viewing Angle

100°

Power Description
Input Voltage

24 V DC

Physical Characteristics
Product Material

Die-cast Aluminum

Durability

Weather Resistant

Height

6.8

Width

3.9

Depth

1

Weight (Approximate)

1.43 lb

Miscellaneous
Application/Usage

Door Entry

Country of Origin

Thailand

Warranty
Limited Warranty

2 Year

Included in the Box

  • icon_list|jp-dv door station|JP-DV Door Station Door unit icon

    JP-DV Door Station

  • icon_list|tamper resistant screws|Tamper Resistant Screws Mounting hardware icon

    Tamper Resistant Screws

FAQs

What are the main features of the Aiphone JP-DV Video Door Phone?
The Aiphone JP-DV is a surface-mount video door phone featuring full-duplex communication, a color camera, and 2-wire connectivity. It includes a CMOS camera with 170° horizontal and 100° vertical viewing angles, built-in microphone, speaker, and call button. The unit is constructed from die-cast aluminum with weather-resistant properties and comes with tamper-resistant screws for secure mounting.
What is the maximum wiring distance for the JP-DV door station?
The JP-DV door station can be installed up to 330 feet from the master monitor using 18AWG 2-conductor solid core cable (Aiphone wire #871802). With additional equipment (JPW-BA long distance adaptor and 851602 cable), the wiring distance can be extended up to 980 feet.
What are the camera specifications of the Aiphone JP-DV?
The JP-DV features a CMOS image sensor with a minimum illumination requirement of 5 lux. It offers an impressive 170-degree horizontal viewing angle and 100-degree vertical viewing angle, providing extensive coverage of the entry area. These specifications ensure clear video monitoring of visitors in various lighting conditions.
What are the physical dimensions and construction of the JP-DV?
The Aiphone JP-DV measures 6.8 inches in height, 3.9 inches in width, and 1 inch in depth, weighing approximately 1.43 pounds. It's constructed from durable die-cast aluminum and features weather-resistant properties, making it suitable for outdoor installation. The unit comes with tamper-resistant screws for secure mounting.
How does the communication system work on the JP-DV?
The JP-DV operates on a full-duplex communication system, allowing natural two-way conversation. When a visitor presses the call button, the indoor master station rings and automatically displays video from the door station's camera. The resident can then initiate communication, while the visitor can speak hands-free at the door station.
