Product details

General Information
Manufacturer

Aiphone Co., Ltd

Manufacturer Part Number

IX-EA

Brand Name

Aiphone

Product Series

IX

Product Model

IXEA

Product Name

IXEA Video Door Phone Sub Station

Product Type

Video Door Phone Sub Station

Camera
Image Sensor Type

CMOS

Camera Resolution

1.2 Megapixel

Minimum Illumination

5 lux

Power Description
Power Consumption

5.18 W

Physical Characteristics
Product Material

ABS

Durability

Weather Resistant

Height

6.3

Width

3.9

Depth

1.7

Miscellaneous
Application/Usage

Door Entry

Compatibility

<p>Aiphone IXG2C7L Video Monitor</p>

Certifications & Standards

  • IEEE 802.3.af
  • IEEE 802.1X

Country of Origin

Thailand

Included in the Box

  • icon_list|door station|Hands-free Door station icon

    Door Station

  • icon_list|installation guide|Installation Guide Documentation icon

    Installation Guide

FAQs

What are the main features of the Aiphone IX-EA Video Door Phone Sub Station?
The Aiphone IX-EA is a weather-resistant IP video door station featuring a 1.23 megapixel fixed color CMOS camera, network connectivity via Cat-5e/6 cable, and SIP compliance. Key features include ONVIF Profile S and RTSP video streaming capability, microSD card support for audio/video recording, and the ability to call up to 20 different stations with three call level selections. It includes a 600Ω output for paging/communication and programmable contact outputs for door release functions.
What are the camera specifications of the IX-EA door station?
The IX-EA features a 1.2 megapixel CMOS camera with a minimum illumination requirement of 5 lux. The camera's angle can be adjusted vertically using a lever located on the back of the station. The video feed can be streamed to third-party devices using either ONVIF Profile S or RTSP protocols, ensuring flexible integration options.
What are the physical dimensions and construction of the IX-EA?
The Aiphone IX-EA measures 6.3 inches in height, 3.9 inches in width, and 1.7 inches in depth. It's constructed from durable ABS material and features weather-resistant construction, making it suitable for outdoor installation. The design allows for surface mounting and ensures durability in various weather conditions.
How does the IX-EA connect to the network and what are its communication capabilities?
The IX-EA connects to networks using Cat-5e/6 cable and is SIP compliant. It supports IEEE 802.3af and IEEE 802.1X standards for secure networking. The station can call up to 20 different stations with three call level selections and includes a 600Ω output for paging or communication purposes. It also supports video streaming via ONVIF Profile S or RTSP protocols.
What customization options are available on the IX-EA?
The IX-EA offers several customization options including uploadable sound files for custom messages during various functions such as door release, call placement, communication start, and error messages. The station can be programmed with up to 20 different call destinations and features three different call level selections. The contact output can be customized to trigger based on door release, 600Ω output usage, or station status.
