Eaton 9PX6K UPS shown in both rack mount and tower orientations with LCD display panels and ventilated front grilles

Dual Installation Options: 3U Rack Mount or Tower Configuration

The Eaton 9PX6K UPS showcases its adaptable design with both rack mount and tower installation capabilities. The sleek 3U form factor features a high-contrast LCD display panel for real-time monitoring and an advanced ventilation system with honeycomb grilles for optimal thermal management. The unit's robust construction combines industrial-grade steel housing with precision engineering for maximum reliability in critical power applications. The intuitive front panel interface provides comprehensive power metrics and system status at a glance, while the modular design enables quick access for maintenance and battery replacement. This versatility makes it ideal for data centers, network closets, and edge computing environments where space optimization and reliable power protection are essential.

Technical Specifications

  • 3U rack height optimized for standard 19-inch equipment racks
  • Dual LCD displays with real-time power monitoring and diagnostics
  • Hot-swappable battery design with tool-less access

Applications

  • Data center rack deployment with minimal space requirements
  • Network closet installation with flexible mounting options
  • Edge computing environments requiring reliable power protection

Product details

General Information
Manufacturer

Eaton Corporation

Manufacturer Part Number

9PX6K

Brand Name

Eaton

Product Series

9PX

Product Name

9PX6K 6kVA Tower/Rack Mountable UPS

Product Type

Double Conversion Online UPS

Technical Information
Plug/Connector Type

NEMA L6-30P

Receptacle Type

NEMA L6-20R
NEMA L6-30R
Hardwired

Receptacle Detail

1 x NEMA L6-20R
2 x NEMA L6-30R

Transfer Time

0 ns

Overload Protection

Yes

Power Description
Load Capacity

6000 VA

Input Voltage

220 V AC
110 V AC

Output Voltage

230 V AC
200 V AC
220 V AC
208 V AC
240 V AC

Input Frequency

70 Hz

Output Frequency

60 Hz

Management
Network Management

SNMP Manageable

Bypass Switch

Optional

Emergency Power OFF

Yes

Interfaces/Ports
Serial Port

Yes

Network (RJ-45)

Yes

USB

Yes

Battery Information
Battery Characteristics

Maintenance-free/Sealed

Battery Chemistry

Lead Acid

Backup/Run Time (Full Load)

3 Minute

Backup/Run Time (Half Load)

8 Minute

Physical Characteristics
Form Factor

Rack/Tower

Rack Height

3U

Height

5.1

Width

17

Depth

28

Weight (Approximate)

105.82 lb

Miscellaneous
Package Contents

  • 9PX6K 6kVA Tower/Rack Mountable UPS
  • Network-MS Web/SNMP Card
  • 4-Post Rail Kit
  • User Manual
  • Quick Start Guide
  • Tower Pedestals
  • Intelligent Power Software Suite CD
  • RS-232 Serial Cable
  • USB Cable
  • Cable Gland for Hardwire Conection
  • Phillips Head Screw Driver

Software Included

Eaton Intelligent Power Software

Environmentally Friendly

Yes

Environmental Certification

RoHS

Country of Origin

Philippines

Warranty
Limited Warranty

2 Year

FAQs

What is the power capacity of the Eaton 9PX6K UPS?
The Eaton 9PX6K UPS has a power capacity of 6000VA/5.4kW at 208V. This robust capacity makes it ideal for protecting critical IT equipment, including Cisco switches and servers in educational, commercial, financial, or healthcare networking environments.
What type of outlets does the Eaton 9PX6K UPS provide?
The Eaton 9PX6K features two NEMA L6-20R and two NEMA L6-30R managed outlets, plus hardwired output capability. All outlets provide pure sine wave AC output and allow for power consumption monitoring at the outlet group level. The outlets are fully protected against surges and line noise to safeguard connected equipment.
What is the form factor and physical dimensions of the 9PX6K?
The Eaton 9PX6K is a versatile 3U rack/tower convertible UPS that measures 5.1" in height, 17" in width, and 28" in depth. Weighing 105.82 lbs, it can be mounted in a standard 19" rack using the included 4-post rail kit or set up in tower configuration using the provided tower pedestals.
What is the battery runtime of the Eaton 9PX6K?
The Eaton 9PX6K provides 3 minutes of runtime at full load and 8 minutes at half load with its built-in maintenance-free lead acid batteries. Runtime can be extended by connecting up to four optional 9PXEBM180RT extended battery modules (sold separately) for hours of additional backup time.
What network management capabilities does the 9PX6K include?
The 9PX6K comes with a NETWORK-M2 Gigabit network card that enables comprehensive remote management including configuration, load shedding, equipment reboots, and safe shutdowns. The card meets UL 2900-1 and IEC 62443-4-2 cybersecurity standards and allows remote firmware updates without dropping the load. It's also compatible with the optional Environmental Monitoring Probe Gen 2 for temperature and humidity monitoring.
