StarTech 4 Port VGA Over CAT5 Video Extender - 450ft (150m) (ST1214T)

Name: StarTech 4 Port VGA Over CAT5 Video Extender - 450ft (150m) (ST1214T)
Brand: StarTech.com
SKU: ST1214T
Price: 145.94 USD
Availability: InStock

by StarTech.com

Authorized Partner

Availability:

in stock, ready to be shipped

$145.94 - $145.94

$145.94

$145.94 - $145.94

$145.94

New

FREE SHIPPING FOR DOMESTIC ORDERS

Delivery time

We ship orders 24-48 hours after they have been placed. We do not charge before we ship them out. It might take up to an additional 48 hours to ship international orders.

The ST1214T 4 Port VGA Video Extender over Cat 5 allows a single VGA source to be broadcast to up to four remote displays at distances of up to 500 feet (150 meters). Designed for use with our ST121 VGA Video over Cat 5 extension series of devices, the ST1214T is one of many options designed to help you create a custom VGA distribution and extension solution for many applications including digital signage and video conferencing.

Consisting of the transmitter unit only, this product requires a single [%product id="ST121R" text="ST121R"%] receiver unit per remote display that you are connecting. If you are looking for an eight port transmitter solution, we offer our [%product id="ST1218T" text="ST1218T"%] 8 port VGA extender unit.

For even more versatility, the [%product id="ST121EXT" text="ST121EXT"%] VGA over Cat 5 Repeater can be used to increase the total VGA extension distance by an additional 500 feet(150 meters), allowing the original VGA signal to be broadcast a total distance of 1000 feet (300 meters) from transmitter to receiver. Similarly, up to three repeater units can be used between the transmitter and receiver units allowing a monitor to be connected at each repeater station , while further extending the total distance between the transmitter and receiver units.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

StarTech.com ST1214T Tech Specs

General Information
Manufacturer:	StarTech.com
Manufacturer Part Number:	ST1214T
Brand Name:	StarTech.com
Product Name:	4 Port VGA Video Extender over Cat 5
Product Type:	Video Extender Transmitter

Technical Information
Connectivity Technology:	Wired
Number of Input Devices Supported:	1
Maximum Operating Distance:	492.13 ft

Video
Graphics Modes:	VGA
Maximum Video Resolution:	1600 x 1200

Interfaces/Ports
Network (RJ-45):	Yes
VGA In:	Yes
VGA Out:	Yes
Number of Network (RJ-45) Ports:	4
Number of VGA Inputs:	1
Number of VGA Outputs:	1

Media & Performance
Media Type Supported:	Twisted Pair
Twisted Pair Cable Standard:	Category 5

Power Description
Input Voltage:	9 V DC

Physical Characteristics
Product Color:	Black
Transmitter Height:	0.80"
Transmitter Width:	2.50"
Transmitter Depth:	4.10"
Form Factor:	Desktop
Transmitter Weight (Approximate):	7.09 oz

Miscellaneous
Package Contents:	4 Port VGA Video Extender over Cat 5 4 x Rubber Feet 1 x Universal Power Adapter (NA/UK/EU)
Environmentally Friendly:	Yes
Environmental Certification:	RoHS
	WEEE
	REACH
Country of Origin:	Taiwan
TAA Compliant:	Yes

Warranty
Limited Warranty:	2 Year
