Top view of StarTech.com 2-port HDMI switch showing control interface and status indicators

4K HDMI Switch with Intuitive Control Interface

The StarTech.com VS221HD4KA features a sleek top panel design with clear input indicators and control options. The device's intelligent interface allows for seamless switching between two HDMI sources while maintaining crystal-clear 4K video quality. The front panel includes status LEDs and easy-access buttons for effortless source selection.

Technical Specifications

  • HDCP-ready certification for content protection
  • LED indicators for active input monitoring
  • Front panel tactile buttons for manual control

Applications

  • Conference room display management
  • Digital signage source control
  • Professional AV installations
Detailed view of StarTech.com HDMI switch control panel and configuration options

Advanced Control and Configuration Options

The top panel reveals comprehensive control options including auto-switching capabilities and EDID management. Clear labeling and intuitive layout make setup and operation straightforward. The device supports multiple switching modes and provides visual feedback for active connections and settings.

Technical Specifications

  • EDID copy functionality
  • Multiple switching mode options
  • Auto-sensing capability

Applications

  • Automated display management
  • Priority-based source switching
  • Multi-format display compatibility

Product details

General Information
Manufacturer

StarTech.com

Manufacturer Part Number

VS221HD4KA

Brand Name

StarTech.com

Product Name

2-Port HDMI Automatic Video Switch - 4K with Fast Switching

Packaged Quantity

1

Product Type

Audio/Video Switchbox

Technical Information
Connectivity Technology

Cable

Number of Input Devices Supported

2

Device Supported

A/V Receiver
Computer
Set-top Box
Display
Blu-ray Disc Player
DVD Player
Gaming Console
Projector

Number of Displays Supported

1

Video
Graphics Modes

4K

Maximum Video Resolution

3840 × 2160

Interfaces/Ports
HDMI In

Yes

HDMI Out

Yes

Number of HDMI Inputs

2

Number of HDMI Outputs

1

Physical Characteristics
Height

2.5

Width

0.9

Depth

0.6

Weight (Approximate)

1.84 lb

Miscellaneous
Package Contents

  • 2-Port HDMI Automatic Video Switch - 4K with Fast Switching
  • 1 x Remote Control
  • 1 x Universal Power Adapter (NA/EU/UK/AU)
  • 1 x RJ11 Cable
  • 1 x RJ11 to DB-9 Serial Adapter
  • 1 x Mounting Kit
  • 1 x Quick Start Guide

Environmentally Friendly

Yes

Environmental Certification

REACH
WEEE
RoHS

Country of Origin

Taiwan

TAA Compliant

Yes

Warranty
Limited Warranty

2 Year

Included in the Box

  • icon_list|Main unit|Lift Ergo Mouse Main unit icon

    HDMI Switch - Main unit

  • icon_list|remote control|EHS Remote control icon

    IR Remote - Remote control

  • icon_list|power supply|5V 3A Power supply icon

    Power Adapter - Power supply

FAQs

What is the maximum resolution supported by the StarTech.com VS221HD4KA HDMI switch?
The StarTech.com VS221HD4KA supports Ultra HD 4K resolution with a maximum resolution of 3840 × 2160 pixels. This provides four times the resolution of 1080p, delivering 8.29 million pixels versus 2.07 million pixels, ensuring exceptional image clarity and visibility for high-quality display output.
How many devices can be connected to this HDMI switch?
This HDMI switch supports two input devices and one output display. You can connect two HDMI source devices (such as Blu-ray players, gaming consoles, computers, or set-top boxes) and switch between them to display on a single monitor, TV, or projector.
What are the different switching modes available on the VS221HD4KA?
The VS221HD4KA offers three switching modes: 1) Fast auto-switching with advanced auto-sensing that automatically detects and switches to the latest connected source, 2) Priority switching that allows one port to take precedence when multiple sources are connected, and 3) Manual switching using front-panel buttons or the included IR remote control.
What comes included in the package?
The package includes the 2-Port HDMI Automatic Video Switch, an IR remote control, a universal power adapter (NA/EU/UK/AU), an RJ11 cable, an RJ11 to DB-9 serial adapter, a mounting kit, and a quick start guide. All necessary components for complete setup and operation are provided.
What devices are compatible with this HDMI switch?
The VS221HD4KA is compatible with multiple devices including A/V receivers, computers, set-top boxes, displays, Blu-ray disc players, DVD players, gaming consoles, and projectors. The switch features EDID emulation to ensure maximum compatibility and optimal display settings with 4K displays.
