Close-up view of blue LC connectors with white strain relief and yellow cable jacket on AddOn single-mode fiber patch cable

High-Performance LC Connectors for Reliable Data Transmission

The AddOn single-mode fiber patch cable features precision-engineered LC connectors designed for optimal signal integrity. The blue LC connectors with white strain relief boots provide secure termination while protecting the delicate fiber core. The yellow LSZH jacket offers durability and flame-retardant properties essential for enterprise network installations. This 10-meter simplex cable utilizes 9/125 micron single-mode fiber optimized for 1310nm and 1550nm wavelengths. The molded construction ensures consistent performance and reliability in demanding data center and telecommunications applications.

Technical Specifications

  • Single-mode 9/125 micron core/cladding for long-distance transmission
  • Molded LC connectors with precision ceramic ferrules
  • LSZH yellow jacket for safety and compliance

Applications

  • Data center interconnects requiring high bandwidth
  • Telecommunications infrastructure deployment
  • Enterprise network backbone connectivity
Angled detail shot of LC connector assembly showing blue housing, white strain relief and yellow cable on AddOn fiber patch cable

Enhanced Connector Design for Maximum Signal Quality

The angled perspective highlights the superior build quality of the LC connector assembly. The blue housing incorporates a push-pull latch mechanism for secure connectivity, while the white strain relief provides crucial cable protection at the termination point. The precisely molded connector ensures optimal fiber alignment for minimal signal loss. The yellow single-mode cable maintains consistent bend radius control through the strain relief transition, protecting the internal fiber core. This attention to mechanical design details results in reliable high-speed data transmission across the full 10-meter cable length.

Technical Specifications

  • Push-pull latching mechanism for secure connections
  • Integrated strain relief system for cable protection
  • Premium ceramic ferrule for precise fiber alignment

Applications

  • Mission-critical network infrastructure
  • High-density patch panel installations
  • Core switching and routing connections

Product details

General Information
Manufacturer

AddOn

Manufacturer Part Number

ADD-LC-LC-10MS9SMF

Brand Name

AddOn

Product Name

10m Single-Mode fiber (SMF) Simplex LC/LC OS1 Yellow Patch Cable

Product Type

Network Cable

Technical Information
Cable Type

Fiber Optic

Cable Characteristic

Patch Cable

Fiber Optic Mode

Single-mode

Core/Cladding Diameter

9/125 µm

Cable Length

32.81 ft

Connector Type on First End

LC Network - Male

Connector on First End Details

1 x LC Network - Male

Connector Type on Second End

LC Network - Male

Connector on Second End Details

1 x LC Network - Male

Features

Molded

Jacket Type

LSZH

Device Supported

Network Device

Physical Characteristics
Product Color

Yellow

Jacket Material

Low Smoke Zero Halogen

Height

13

Width

11

Weight (Approximate)

0.40 lb

Miscellaneous
Country of Origin

United States

Warranty
Limited Warranty

3 Year

FAQs

What are the key specifications of the AddOn LC/LC fiber patch cable?
The AddOn LC/LC patch cable is a 10-meter (32.81 ft) single-mode fiber (SMF) simplex cable with OS1 specification. It features LC male connectors on both ends, uses a 9/125 micron core/cladding diameter, and comes with a yellow LSZH (Low Smoke Zero Halogen) jacket. The cable is designed for wavelengths of 1310nm and 1550nm with a maximum attenuation of 1dB/km.
What type of connectors does this fiber cable use and what is their configuration?
This cable uses LC (male) connectors on both ends in a simplex configuration. The simplex design means it's a single-strand fiber cable, making it ideal for bi-directional transceivers and single-transmitting devices. Both the first and second ends feature 1 x LC Network Male connector.
What is the cable's jacket material and why is it important?
The cable uses an LSZH (Low Smoke Zero Halogen) jacket material. This is particularly important for safety in indoor installations as it produces minimal smoke and no halogenic gases in case of fire. The LSZH construction makes it ideal for use in environments where protecting people and equipment from toxic fumes during a fire event is crucial.
What is the maximum length and physical specifications of this cable?
The cable is 10 meters (32.81 feet) in length. It has dimensions of 13" height and 11" width, with an approximate weight of 0.40 lb. The yellow color coding helps in easy identification and management of the cable in complex network installations.
What type of fiber mode does this cable use and what are its applications?
This is a single-mode fiber (SMF) cable with OS1 specification, using a 9/125 micron core/cladding diameter. It's optimized for use with wavelengths of 1310nm and 1550nm, making it ideal for long-distance network connections and high-bandwidth applications where minimal signal loss is crucial.
