Thermaltake

PS-TPT-0750FNFAGU-W

¥24,500

Thermaltake Toughpower GT Snow 750W Power Supply, 80 Plus Gold, ATX 3.1, PCIe Gen 5.1 Ready, Fully Modular, 120mm Fan, Zero Fan Mode, White - PS-TPT-0750FNFAGU-W (5 Year Warranty)

Name: Thermaltake Toughpower GT Snow 750W Power Supply, 80 Plus Gold, ATX 3.1, PCIe Gen 5.1 Ready, Fully Modular, 120mm Fan, Zero Fan Mode, White - PS-TPT-0750FNFAGU-W (5 Year Warranty)
Brand: Thermaltake
SKU: PS-TPT-0750FNFAGU-W
Price: 24500 JPY
Availability: InStock

Brand New

Tokyo to Osaka, Yokohama to Nagoya – We've Got Japan Covered

Input Voltage:

120 V AC See available options
230 V AC See available options

Output Power:

500 W See available options
600 W See available options
700 W See available options
750 W See available options
850 W See available options
1000 W See available options
1050 W See available options
1200 W See available options

Product variants

750W

Power Output

80+ Gold

90% Efficiency

ATX 3.1

PCIe Gen 5.1

Fully Modular

All Cables

Zero Fan

Silent Mode

120mm Fan

Hydraulic Bearing

Hurry, only 5 items left in stock!

Share:

Share

Need help?

Ask Our Experts

Live Chat Send Message

Call Us

888.267.9566

Pairs well with

In stock! Ships within 1-3 business days.

30 days Return

Limited warranty: 5 Year

Key Features

⚡ 750W ATX 3.1 Ready Power Supply with 80 PLUS Gold certification (90% efficiency)
🔌 PCIe Gen 5.1 Ready with native 12V-2x6 (12+4 pin) connector supporting up to 600W
🌪️ Ultra-quiet 120mm Hydraulic Bearing Fan with Smart Zero Fan technology
⚙️ Fully modular design with low-profile white cables for easy management
🛡️ Complete protection suite: OCP, OVP, UVP, OPP, SCP, and OTP
💪 Single +12V rail delivering 62.5A for maximum compatibility
🔧 6x SATA, 4x PCIe (6+2 pin), and 2x CPU (4+4 pin) connectors
⏳ Backed by a 5-year warranty
❄️ Stylish snow white design for aesthetic builds
🌡️ Operating temperature range: 0°C to 40°C

Thermaltake Toughpower GT S...

¥24,500

Product details

General Information

Manufacturer

Thermaltake Technology Co., Ltd

Manufacturer Part Number

PS-TPT-0750FNFAGU-W

Brand Name

Thermaltake

Product Line

Toughpower

Product Series

GT

Product Model

TPD-750AH2FXG-3

Product Name

Toughpower GT Snow 750W

Product Type

Power Supply

Technical Information

Specification Compliance

ATX 3.1

Efficiency

90%

Power Factor Correction (PFC)

Active

Number of Fans

1

Fan Diameter

120 mm

Protection Type

Short Circuit
Over Current
Over Voltage
Under Voltage
Over Power
Over Temperature

Modular

Yes

Power Description

Number of +12V Rails

1

Input Voltage

120 V AC
230 V AC

Output Voltage

-12 V DC
12 V DC
5 V SB
3.3 V DC
5 V DC

Output Voltage Detail

12 V DC @ 62.5 A
5 V SB @ 3 A
5 V DC @ 20 A
-12 V DC @ 0.3 A
3.3 V DC @ 20 A

Output Power

750 W

Input Frequency

60Hz

Interfaces/Ports

Number of SATA Power Connectors

6

PCI Express Connector

Yes

Number of (6+2 pin) PCI Express Power Connectors

4

Number of (4+4 pin) CPU Power Connectors

2

Environmental Conditions

Minimum Operating Temperature

32°F (0°C)

Maximum Operating Temperature

104°F (40°C)

Physical Characteristics

Color Family

White

Product Color

Snow

Form Factor

Internal

Height

3.4''

Width

5.9''

Depth

5.5''

Miscellaneous

Certifications & Standards

<ul><li data-list=''bullet''>CE</li><li data-list=''bullet''>UKCA</li><li data-list=''bullet''>ICES</li><li data-list=''bullet''>TUV</li><li data-list=''bullet''>LVD</li><li data-list=''bullet''>RCM</li><li data-list=''bullet''>CB</li><li data-list=''bullet''>FCC</li><li data-list=''bullet''>cTUVus</li><li data-list=''bullet''>BSMI</li><li data-list=''bullet''>CCC</li><li data-list=''bullet''>BIS</li><li data-list=''bullet''>S-MARK</li></ul>

Energy Efficiency Certification

80 Plus Gold

Warranty

Limited Warranty

5 Year

Included in the Box

Power Supply Unit
Modular Cables
PCIe 12+4 Cable
AC Power Cord
User Manual
Mounting Screws

FAQs

What are the key features of the Thermaltake Toughpower GT Snow 750W power supply?

The Thermaltake Toughpower GT Snow 750W is a fully modular power supply featuring 80 PLUS Gold certification with up to 90% efficiency. It's ATX 3.1 compatible, includes PCIe Gen 5.1 support with a 12V-2x6 connector, and features a quiet 120mm Hydraulic Bearing Fan with Smart Zero Fan technology. The PSU offers a single +12V rail design, comprehensive protection features (OCP, OVP, UVP, OPP, SCP, OTP), and comes with low-profile white cables for easier cable management. It's backed by a 5-year warranty and can deliver up to 600W for PCIe 12+4pin graphics cards.

What connectors and ports does the Toughpower GT Snow 750W include?

The Toughpower GT Snow 750W comes with a comprehensive set of connectors including 6 SATA power connectors, 4 PCIe (6+2 pin) power connectors, and 2 CPU power connectors (4+4 pin). It also features the new PCIe 12V-2x6 (12+4 pin) connector for next-generation GPUs, supporting up to 600W power delivery. All cables are fully modular and feature a low-profile white design for improved cable management and system aesthetics.

What are the power specifications and output capabilities of this PSU?

This 750W power supply features a single +12V rail delivering 62.5A. The PSU provides multiple output voltages: 12V DC @ 62.5A, 5V DC @ 20A, 3.3V DC @ 20A, -12V DC @ 0.3A, and 5V SB @ 3A. It supports input voltages of 120V AC and 230V AC at 60Hz frequency. The unit is 80 PLUS Gold certified, achieving up to 90% efficiency, and supports ATX 3.1 specifications with up to 200% power excursion capability.

What protection features does the Toughpower GT Snow 750W include?

The Toughpower GT Snow 750W includes comprehensive industrial-grade protection features: Over Current Protection (OCP), Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP), and Over Temperature Protection (OTP). These protection mechanisms ensure safe operation and help prevent damage to both the power supply and connected components.

What are the cooling features of this power supply?

The power supply features a 120mm Hydraulic Bearing Fan with Smart Zero Fan technology. This cooling system is designed to maintain low friction levels and operates with intelligent speed control to minimize noise. The Smart Zero Fan function automatically adjusts fan speed based on load and temperature, ensuring optimal cooling while maintaining quiet operation. The PSU can operate in temperatures ranging from 32°F (0°C) to 104°F (40°C).
